LCD Interface

5.2

S1D13C00 VDD and Panel I/O Supply Selection

5.2.1
Jumpers Descriptions
JP3 VCOMVDD Selection
JP4 DISPVDD Selection
JP6 VDD Selection

SPI Panels (on J3) Power and Control Selection

5.2.2
Jumpers Descriptions
JP7 EXTMODE Selection
JP8 VDDA Selection
JP9 VDD Selection
JP10 EXTVCOM Selection
J3_DISP_EN
JP20
Selection
Jumpers Descriptions
Display Enable
JP11
Control Selection

Power Supply

5.3
Jumpers
VDD Supplies on pin 22 and pin 34 of S1D13C00
JP1
(used for current measurement)
External 5V Power Supply
JP5 JP5-1 = +5V in
JP5-2 = GND
JP13 External VC3 Supply connection
Customer Development Board User Manual
(Rev 1.01)
1-2 Position
VMDL
VMDL
VDD_3V3
1-2 Position
External VCOM
VMDH
VMDH
VCOM
(for JP7 = 1-2)
PA5 of Host MCU
(pin 20 on J6)
1-2 Position
3-4 Position
J3_VDD J3_DISP_EN
(Always enable) (see JP20)
Descriptions
Seiko Epson Corporation
2-3 Position
VMDH
VMDH
HOST_3V3
2-3 Position
Internal VCOM
VMDL
VMDL
GND
(for JP7 = 2-3)
P07 of S1D13C00
(pin 30)
5-6 Position
GND
(Disable)
Default Settings
No Connection (NC)
No Connection (NC)
Jumpers Settings
Default Position
1-2 (VMDL)
1-2 (VMDL)
1-2 (VDD_3V3)
Default Position
1-2 (External VCOM)
2-3 (VMDL)
2-3 (VMDL)
1-2 (VCOM)
2-3 (P07 of S1D13C00)
Default Position
3-4 (controlled by JP20)
Install
