DIP-Switch and Headers

DIP-Switch and Headers
6.
Figure 7 – S5U13C00P00CX00 DIP-Switch and Headers Locations

DIP-Switch (S1)

6.1
The main purpose of the DIP-switch is used to perform a loopback test on both of the SPI interfaces of the
S1D13C00. During normal operations, all the switches should be OFF (default setting).
The table below shows the pin assignments of S1. When the switch is ON, the corresponding signals are connected.
S1
Pin
1
2
3
4
(1) When performing loopback test, R51 in series of #QSPISS needs to be removed
10
R51
S1D13C00 S1 ON Connection
Pin Name
#QSPISS
QSPICLK
QSPID0
QSPID1
Seiko Epson Corporation
< -- > P00 (#SPISS)
< -- > P01 (SPICLK)
< -- >
< -- >
S1
H2
H1
S1D13C00 S1
Pin Name Pin
8
7
P02 (SPIDI) 6
P03 (SPIDO) 5
Customer Development Board User Manual
(Rev 1.01)
