Parts List

10. Parts List

Item Qty Reference
1 1 BZ1
2 2 C1,C2
3 18 C3,C7,C8,C9,C11,C12,
C13,C14,C15,C16,
C18,C19,C21,C22,
C24,C28,C31,C32
4 2 C4,C6
5 2 C5,C37
6 1 C10
7 6 C17,C20,C23,C29,
C30,C33
8 3 C34,C35,C36
9 1 D1
10 1 H1
11 1 H2
12 3 JP1,JP5,JP13
13 15 JP2,JP3,JP4,JP6,JP7,
JP8,JP9,JP10,JP14,
JP15,JP16,JP17,JP18,
JP19,JP20
14 1 JP11
15 1 J1
16 1 J2
17 1 J3
18 4 J4,J5,J6,J7
19 1 LED1
20 1 LED2
21 1 Q1
22 1 R1
23 4 R2,R59,R67,R73
24 56 R3,R5,R6,R12,R13,R14,
R15,R16,R17,R18,R19,
R20,R21,R22,R23,R24,
R25,R26,R27,R28,R29,
R30,R31,R32,R33,R34,
R35,R36,R37,R38,R39,
R40,R41,R42,R43,R44,
R45,R46,R47,R48,R49,
R51,R52,R53,R54,R55,
R56,R61,R63,R65,R68,
R69,R70,R71,R72,R75
25 1 R4
Item Qty Reference
26 2 R50,R58
18
Part
BUZZER 1.2cm x 1.2cm SMD Buzzer
10pF Ceramic 1% 50V COG/NPO C0603
10pF
1uF 1.0uF Ceramic 10% 16V X5R C0603
3.3uF 3.3uF Ceramic 10% 16V X5R C0603
0.1uF 0.1uF Ceramic 10% 16V X5R C0603
10uF 10uF Ceramic 10% 25V X5R C0805
1nF 1nF Ceramic 10% 16V X7R C0604
0.1uF 0.1uF Ceramic 10% 16V X7R C0402
DIODE SCHOTTKY DIODE SCHOTTKY 30V 200MA
HEADER 8x1 CONN HEADER 8POS .100 STR 30AU
HEADER 6x1 CONN HEADER 6POS .100 STR 30AU
HEADER 2x1 BERGSTIK II .100" SR STRAIGHT
HEADER 3x1 BERGSTIK II .100" SR STRAIGHT
HEADER_3X2 CONN HEADER 6POS .100 STR 15AU
CONN_FLEX_24 CONN FPC/FFC 24POS 0.50MM
CONN_FLEX_21 CONN FPC BOTTOM 21POS 0.30MM R/A
CONN_FLEX_10 CONN FPC 10POS 0.50MM R/A
HEADER_10X2 CONN HOUSING 20POS 2.54MM DUAL
LED +3.3V Green LED GREEN DIFFUSED 0603 SMD
EMITTER IR EMITTER IR 940NM 100MA T 1 3/4
MOSFET MOSFET N-CH 20V 0.25A
1K 1K OHM 5% 1/16W SMD R0402
0 0 OHM 1/8W SMD R0805
0 0 OHM 1/8W SMD R0603
560 560 OHM 1% 1/8W SMD R0603
Part
10K 10K OHM 5% 1/10W SMD R0603
Seiko Epson Corporation
Description
Description
Customer Development Board User Manual
Manufacturer Part No. /
Comments
Murata PKLCS1212E4001-R1
Murata GRM1885C1H100FA01
Kemet C0603C105K4PACTU
TDK C1608X5R1C335K080AC
Kemet C0603C104K4PAC7867
Kemet C0805C106K3PAC7800
Murata GRM188R71C102KA01D
Kemet C0402C104K4RACTU
Micro Commercial Co.
BAT42W-TP
Amphenol FCI 68000-108HLF
Amphenol FCI 68000-106HLF
Amphenol FCI 68000-102HLF
Amphenol FCI 68000-103HLF
Amphenol FCI 67997-206HLF
Hirose FH34SRJ-24S-0.5SH(99)
Molex 503566-2100
Omron XF2W-1015-1A
Hirose HIF3H-20DA-2.54DSA(71)
Stanley Electric PY111C-TR
LITEON LTE-5208A
Toshiba SSM3K37MFV,L3F
Yageo C0402JR-071KL
Yageo RC0805JR-070RL
Vishay MCT06030Z0000ZP500
Vishay MCT06030C5600FP500
Manufacturer Part No. /
Comments
Yageo RC0603JR-0710KL
(Rev 1.01)
