Tiva C Series EK-TM4C1294XL Launchpad Connections
J6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
J7
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
14
EK-TM4C1294XL
Connector X6 Signals
3V3
5V
PD2
GND
PP0
PB4
PP1
PB5
PD4
PK0
PD5
PK1
PQ0
PK2
PP4
PK3
PN5
PA4
PN4
PA5
EK-TM4C1294XL
Connector X7 Signals
PG1
GND
PK4
PM7
PK5
PP5
PM0
PA7
PM1
TARGET_RST#
PM2
PA3/PQ2
PH0
PA2/PQ3
PH1
PP3
PK6
PQ1
PK7
PM6
Seiko Epson Corporation
S1D13C00 MDC
BoosterPack Usage
HOST_3V3
HOST_5V
-
GND
-
#HIFDE
-
to JP14-3 as HIFSPICLK
to JP17-3 as HIFSPID2
to JP15-1 as HIFD0
to JP18-3 as HIFSPID3
to JP16-1 as HIFD1
-
to JP17-1 as HIFD2
-
to JP18-1 as HIFD3
-
-
-
To JP20-1 as J3_DISP_EN
S1D13C00 MDC
BoosterPack Usage
-
GND
-
-
-
-
-
-
-
-
-
-
-
-
-
#HIFCS
-
-
-
-
