Assign The Netlink Oai Gateway's Ip Address - SpectraLink NetLink MOG600 Installation Manual

SpectraLink Corporation
3.2

Assign the NetLink OAI Gateway's IP Address

You can administer the NetLink OAI Gateway via Telnet connection from the NetLink
Administration Console. However, as with the Telephony Gateways, the NetLink OAI
Gateway must be assigned an IP address before you can connect using Telnet.
The following steps outline the procedure to assign the IP address to the NetLink OAI
Gateway.
1. Connect a terminal or PC to the Gateway's serial port using a cable that conforms
to RS-232 standards for DTE to DTE connections (known as a null modem
cable).
2. Reset the system. The following OAI command will display on the terminal:
.
04830130
3. Type the following command on the terminal or PC keyboard:
0255CC [CTRL-M] [CTRL-J].
Note that this command will not display on the screen as it is typed.
4. The prompt should display. If you made an error entering the command
Login
string, the message for "Ill Formed Packet" will display (a series of numbers
followed by some version of the command you typed.) Repeat Steps 2 and 3 until
you see the Login prompt.
5. At the prompt, enter the default login:
Login
. These are case sensitive.
admin
6. You can now configure the NetLink OAI Gateway (including IP address)
following the procedure explained in the next section.
Changing the IP Address
When utilizing the serial port as the primary communication link with the application
server, the OAI command described in step two above must be entered to free the port
and allow it to be used for administrative purposes.
Part Number: 72-0078-07-A.doc
LAN
Ethernet
switch
OAI
Gateway
NetLink OAI Gateway
RS-232
port
RS-232
port
(terminal)
and default password:
admin
Installation
Page 14
