SpectraLink Corporation
2.1
System Overview
At a typical site, the NetLink OAI Gateway is connected to the Ethernet switch via an RJ-
45/Category 5 cable and the application server via the RS-232 port. The client system
may include a LAN and its application server with a TAP connection to a
communications device such as a paging controller.
Access Point
Wireless
Telephones
optional
Wireless
Data Device
Device supplied by
SpectraLink
* Note that the wired
telephone system may
include a NetLink
Telephony Gateway
Supplied by SpectraLink
Part Number: 72-0078-07-A.doc
rd
LAN-based 3
Party Applications:
Email Server, LAN Clients, Internet
Ethernet switch
Access Point
Direct Connect 3
Paging Controller, Nurse Call Systems,
Industrial Controllers
(See Application Note for Specific Installation)
Ethernet cable
Phone cabling
RS-232 cable
LAN
Backbone
NetLink OAI Gateway
OAI protocol
RS 232
rd
Server for 3
Party OAI
Application
RS 232
rd
Party Applications
Installation
NetLink OAI Gateway
Wired telephone
system*
Wired
Telephones
Page 11
