SpectraLink PTE140 Technical Bulletin

Using the TFTP Server on the NetLink Gateway with NetLink 2.0
Code
Date:
Software Versions:
Hardware Revisions:
Product Type:
Access Level:

Issue

When using the NetLink Gateway as a TFTP server to load phones with NetLink2.0
software, all unnecessary files need to be removed from the Gateway. This will free up
memory space to allow the FTP of NetLink2.0 software to the Gateway. There is
currently not enough memory to store software for all of the phones.

Description

NetLink2.0 software along with software for the PTB8xx phones will no longer fit in the
gateway simultaneously. This is also true for Gateways with NetLink2.0 and OAI
software.
To remove files from the Gateway, please refer to Technical Bulletin 00-17, "How to
FTP Files to/from the NetLink 150 Telephony Gateway."
http://www.spectralink.com/service/tb/TB-00-17.pdf
Unnecessary files that may need to be removed from Gateway are: pdt02c.bin,
pft02c.bin, pdt06c.bin, phintl.bin, and mog600.bin.

Additional Information

Alternatively, a separate TFTP server may be used to load the NetLink2.0 software and
then download it to the phones.
Every time a phone is powered on it tries to go to a TFTP server to verify the software
version that it has matches the TFTP server. If the files are different, then the phone
will load that software
If the TFTP server (either the gateway or an external TFTP server) does not have the
files, then the phone will give a TFTP error and not recover. If the gateway
configuration has been changed so that "NONE" is selected as the WT TFTP download
master, then the phones will give a brief TFTP error then continue their bootup.
THE INFORMATION PROVIDED IN THE SPECTRALINK TECHNICAL BULLETIN IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY KIND. NO
OBLIGATION OR LIABILITY WILL ARISE OUT OF, SPECTRALINK RENDERING TECHNICAL OR OTHER ADVICE OR SERVICE IN CONNECTION
SpectraLink Corporation • 5755 Central Avenue • Boulder, Colorado 80301 • 303.440.5330 • Fax 303.440.5331
May 23, 2005
All
PTE1xx, PTX1xx, PTN1xx
NetLink Wireless Telephones
General
HEREWITH.
Technical Bulletin CS-05-04
Originator:
Matt Jerger
Approvers:
John Kelley
Wayne McAllister
Mitch Silver
Status:
Approved
Revision:
A
