SpectraLink MOG600 Technical Bulletin

Technical Bulletin 00-17
Bulletin #: CS-00-17
Software Version: Greater than .026
Access Level: General
Status: Approved
Date: September 29, 2000
---------------------------------------------------------------------------------------------------------------------
Title:

How to ftp files to/from the NetLink Telephony Gateway

Description:

It is possible to ftp software files to the gateway, in order to
upgrade/downgrade the gateway and phone firmware. It is also possible to
backup the gateway's configuration data. This document describes these
processes.

Setup:

This document assumes the gateway is already installed and running
properly on an Ethernet LAN. You will need a computer on the same
network to be able to execute the following processes.

Process:

Begin an ftp session to the gateway by opening a DOS window. Proceed to
the folder in which you would like to run ftp from. This folder should contain
the software files to be loaded, and will also be the destination in which all
configuration data will be stored. Type:
>ftp [IP Address of Telephony Gateway]
Login using your normal login and password for the User and Password
prompts:
>User ([IP Address]:(none)): admin
>Password: admin
Set the ftp session to binary mode by typing
ftp>binary
You can then upgrade files that are stored in the gateway by typing
>put [gateway file]
(Note: It is only possible to put files into the gateway if no calls are active on
that gateway. Upgrading a file in the gateway will enable the maintenance
lock, and require the gateway to be reset.)
It is also possible to retrieve the configuration file from the gateway if you'd
like to create a backup copy.
>get [gateway file]
A list of valid gateway files and their descriptions follow. (Note: Names of
these files must match exactly, otherwise the gateway will not receive or
deliver the files.)
fnctla.bin
auxlry.bin
10/02/00
Product Type:
Hardware Revision:
Originator:
Approvers:
Functional code for the Telephony Gateway
(1 of 2 necessary files needed to upgrade gateway firmware)
Auxiliary Image for the Telephony Gateway
All NetLink Telephony Gateways
All
Anthony Paszyna
John Elms, Gary Bliss
