- Page 1 NetLink Telephony Gateway NetLink SVP Server Installation Part Number: 72-0065-01 Issue G...
- Page 2 SpectraLink and shall be neither reproduced in whole or in part without the prior written approval of SpectraLink, nor be implied to grant any license to make, use, or sell equipment manufactured in accordance herewith.
- Page 3 IEC 801-3 RF Radiated IEC 801-4 Fast Transients Additionally, all models comply to EN60950/ IEC950 with CB certificates & reports. February 21, 2002 Mark R. Angliss, Manager; Quality & Process Engineering, For the SpectraLink Corporation DECLARATION OF CONFORMITY Spectralink Corporation 5755 Central Avenue...
-
Page 4: Important Safety Information
Note concerning shielded cable: SpectraLink recommends the use of shielded cable for all external signal connections in order to maintain FCC Part 15 emissions requirements. Note concerning the Wireless Telephones: This device complies with Part 15 of the FCC Rules. - Page 5 If they do, you will be notified in advance to give you an opportunity to maintain uninterrupted telephone service. If you experience trouble with this telephone equipment, please contact SpectraLink Corporation for information on obtaining service or repairs.
- Page 6 SpectraLink Corporation Installation—NetLink Telephony Gateway NetLink SVP Server Industry Canada (IC) Notice Notice: The Industry Canada (IC) label identifies certified equipment. This certification means that the equipment meets telecommunications network protective, operational, and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The department does not guarantee the equipment will operate to the user’s satisfaction.
-
Page 7: Table Of Contents
The Front Panel of the NetLink Telephony Gateway 4. SITE PREPARATION Required Materials LAN Requirements Location of NetLink Telephony Gateway and NetLink SVP Server 5. TELEPHONE INTERFACE CONFIGURATION Prepare Demarc Blocks Install Telephone Demarc Blocks Assign and Program Telephone Ports Connect Telephone Lines to Demarc Blocks 6. -
Page 8: About This Document
This document explains installation of the NetLink Telephony Gateway manufactured by SpectraLink Corporation. The NetLink Telephony Gateway provides telephone functionality to SpectraLink Wireless Telephones over a wireless local area network (LAN). The installation process connects the NetLink Telephony Gateway to an existing host telephone system and LAN. Contacting SpectraLink SpectraLink wants you to have a successful installation. -
Page 9: Installation Overview
– done by the customer or NetLink Telephony Gateway Installation SpectraLink. If five or more NetLink Telephony Gateways are to be installed, a NetLink SVP Server is required and would also be installed in this step. – done by the customer or NetLink Telephony Gateway Configuration SpectraLink per NetLink Telephony Gateway: Setup and Maintenance. -
Page 10: Netlink Overview
Up to forty NetLink Telephony Gateways may be connected to the LAN for a maximum capacity of 640 NetLink Wireless Telephones. When more than four NetLink Telephony Gateways are installed, the NetLink SVP Server must also be installed to manage the increased load. - Page 11 Installation—NetLink Telephony Gateway NetLink SVP Server The following diagram shows the NetLink system architecture with five NetLink Telephony Gateways installed, requiring a NetLink SVP Server. Four or fewer NetLink Telephony Gateways would not require the NetLink SVP Server. Administrative computer...
-
Page 12: System Components
Wireless Telephones must match that used by the access points. Discuss the choice of spread spectrum technology with your access point provider. NetLink Wireless Telephones can operate at up to 11 Mb/s in a DSSS (Direct Sequence Spread Spectrum) system. - Page 13 NetLink SVP Server a required component to utilize the 11Mb/s maximum transmission speed available in the NetLink Wireless Telephone. It is required in any system when five or more NetLink Telephony Gateways are connected to the LAN. With 40 NetLink Telephony Gateway cabled together, the NetLink SVP Server supports a maximum of 640 telephone lines and 120 simultaneous Wireless Telephone calls.
-
Page 14: The Front Panel Of The Netlink Telephony Gateway
– RJ-21 connector to the telephone cross-connect demarc block. Conn A or B Connector B is used only with 4 wire interface. digital NetLink Telephony Gateways that work with the most common brands of telephone systems' (PBX or key systems) digital ports. -
Page 15: Site Preparation
NetLink SVP Server 4. Site Preparation As shown in the system diagram in the previous section, the NetLink Telephony Gateway is connected to both the Ethernet switch and the wired telephone system, the NetLink SVP Server is connected to the Ethernet switch only. The specifications covered here allow for great flexibility in physical placement of the components within stated guidelines. -
Page 16: Location Of Netlink Telephony Gateway And Netlink Svp Server
• For the NetLink Telephony Gateway, a maximum distance of 250 feet from the host telephone switch for a digital interface, and 325 feet (100 meters) from the Ethernet switch. • For the NetLink SVP Server, a maximum distance of 325 feet (100 meters) from the Ethernet switch. Part Number: 72-0065-01-G.doc... -
Page 17: Telephone Interface Configuration
Prepare Demarc Blocks The NetLink Telephony Gateway is connected to the existing telephone system using RJ- 21 connections. A NetLink Telephony Gateway is designed to operate with a specific interface to the telephone system: two-wire digital, two-wire analog, or four-wire digital. -
Page 18: Connect Telephone Lines To Demarc Blocks
This programming will be done after the wireless devices are assigned to the NetLink Telephony Gateway, but will be faster if planned in advance by verifying the parameters and features on the current telephone system and wired phones. - Page 19 SpectraLink Corporation Installation—NetLink Telephony Gateway NetLink SVP Server Two Wire Analog or Digital Demarc Block The demarc block for the two-wire analog or digital interface should be wired as follows. LINE1 ring LINE 2 ring LINE 3 25 PAIR MALE...
- Page 20 NetLink SVP Server Four Wire Digital Demarc Block The four-wire digital interface requires two demarc blocks, one to Connector A and one to Connector B on the NetLink Telephony Gateway. They should be wired as follows. Line 1 TX ring...
- Page 21 SpectraLink Corporation Installation—NetLink Telephony Gateway NetLink SVP Server Line 1 RX ring Line 2 RX ring Line 3 RX 25 PAIR MALE ring CONNECTOR Line 4 RX CABLE TO ring GATEWAY Line 5 RX ring CONNECTOR B Line 6 RX...
-
Page 22: Pre-Installation Verification
Verify Pre-Installation Requirements Check the site to be sure pre-installation work has been completed correctly. This includes: • Location chosen for the NetLink Telephony Gateway is adequate and power is available. • Access points are interoperable with the SpectraLink Voice Priority and coverage is adequate. - Page 23 – Each NetLink Telephony Gateway is shipped with one IPC cable IPC Cable to carry signals between NetLink Telephony Gateways. It is used only when multiple NetLink Telephony Gateways are linked together. You MUST use the IPC cable provided by SpectraLink when connecting four or less NetLink Telephony Gateways.
-
Page 24: Install Netlink Telephony Gateway
13/16 inch by -1/8 2. If installing only one NetLink Telephony Gateway, insert the #8 x 3/4 inch screws in the pilot holes and tighten, leaving a 1/8 to 1/4 inch gap from the wall. 3. If installing more than one NetLink Telephony Gateway, the ESD bonding strap(s) must be installed between adjacent gateways: 3.1 Remove the screws from the bottom (vertical mount) or left (horizontal... - Page 25 Connect NetLink Telephony Gateway to demarc blocks Connect the male RJ-21 connector from the appropriate demarcation block to the designated RJ-21 connector (A or B) on each NetLink Telephony Gateway. Secure the cables using the keeper. Part Number: 72-0065-01-G.doc...
- Page 26 SpectraLink Corporation Installation—NetLink Telephony Gateway NetLink SVP Server Connect four or fewer NetLink Telephony Gateways with IPC cables To connect four or fewer NetLink Telephony Gateways: 1. Mount the NetLink Telephony Gateways. 2. Connect the IPC cable from the Port of the first unit to the...
-
Page 27: Connect Power
To mount five or more NetLink Telephony Gateways: • Mount the NetLink Telephony Gateways on the backboard or rack. • No IPC cable connection is required for five or more NetLink Telephony Gateways. Simply connect each NetLink Telephony Gateway to the local area network via an Ethernet Switch. -
Page 28: Install The Netlink Svp Server
NetLink SVP Server. Use only the provided Class II AC Adapter with output 24VDC, 1A. 5. Plug the AC adapter into a 110VAC outlet to apply power to the NetLink SVP Server. 6. The system will cycle through diagnostic testing and the LEDs will blink for about one minute. -
Page 29: Wireless Device Planning Worksheet
SpectraLink Corporation Installation NetLink Telephony Gateway NetLink SVP Server 9. Wireless Device Planning Worksheet Copy and complete this worksheet to track parameters for each NetLink Telephony Gateway. NetLink Telephony Gateway Hostname: __________________________ MAC: _________________________________ IP Address: ___________________________ Subnet Mask: __________________________... - Page 30 Index Access point, description, 12 Interface Modules, types, 17 Cabling, demarcation blocks, 17 IPC Cables, 23 Connection to Telephone System, 17 NetLink SVP Server, 13 Customer Support Hotline, 8 Mounting, 28 Demarcation blocks NetLink Telephony Gateway Four wire digital, 20...
