A-4 A
PPENDIX
F1 = Help F2 = Keyboard Conventions
This choice allows you to configure your adapter.
Figure A-1 3TLVDIAG Program Main Menu
4 In the main menu, select Adapter Configuration.
To make selections in 3TLVDIAG:
Use the [Tab] key to select buttons, and press [Enter].
Use the arrow keys to select other items, and
press [Enter].
The Adapters Found in System screen appears, listing all
installed 3C339 PCI NICs.
5 In the Adapters Found in System screen, do one of
the following:
If you have a single NIC installed, it is already selected.
Press [Enter].
If you have multiple NICs installed, use the arrow keys
to select a NIC. Press [Enter].
The Adapter Configuration screen for the selected NIC
appears, as shown in Figure A-2.
A: C
ONFIGURATION
3Com 3TLVDIAG
Adapter Configuration
Adapter Diagnostics
Continue
Main Menu
Exit
