The Diagnostic Test screen appears, as shown in
Figure 4-3.
3C3X9
Select the number of iterations to run the tests:
Full Test Suite:
Adapter Register Test:
EEPROM Checksum Test:
Adapter Memory Test:
Transmit In Wrap Tests:
Transmit In Insert Tests:
Main Menu
F1 = Help F2 = Keyboard Conventions
Runs through all the tests listed below.
Figure 4-3 Diagnostic Test Screen
8 To run all the tests once (one iteration of the test
suite), select Run Diagnostics.
The number entered in the Full Test Suite field is the
number of times the test suite will run.
To run the tests individually or in various combinations,
enter 0 in the Full Test Suite field. Then enter the number
of times you want a test to run in the field next to its
name. Then select Run Diagnostics.
If the NIC fails a test, an information screen appears.
For a description of each test, press [F1] to access help.
The following message indicates that all tests have passed:
Diagnostics have completed with the status
of PASSED.
9 Select Exit to exit the diagnostic tests.
10 Remove the TokenDisk diskette and reboot
the computer.
