Draper FlexShade C MO Series Installation & Operation Instructions page 9

Motorized FlexShade
Contact
Closure
Interface
Network
Device Connector
Network
Device Connector
Wall Switch
Data Cable
with RJ45
Connector
by Electrician
®
(Coupled)
Controls & System Overview
AV Gateway
Handheld
Remote
Network
Device Connector
Network
Device Connector Device Connector
RS485
120VAC
Motor
M12
Connectors
B W G
110-120V Line
Data Cable Pin-Out - RJ45 Connector
1 - ORANGE/WHITE
2 - ORANGE
3 - GREEN/WHITE
4 - BLUE
5 - BLUE/WHITE
6 - GREEN
7 - BROWN/WHITE
8 - BROWN
120VAC Motors
Wireless
Device Connector
Gateway
Network
Device Connector
RS485
120VAC
Motor
B W G
Data Cable
with RJ45
Connector
Dashed Wiring
by Electrician
110-120V Line
Contact
Closure
Interface
Network
Network
Wall Switch
page 9 of 10
