Section 10 - Electrical Connections - Draper FlexShade C MO Series Installation & Operation Instructions

Motorized FlexShade

Section 10 - Electrical Connections

Controls & System Overview
Sonesse 120VAC Motors
NOTE: Test shade operation
120V
If shade direction does not
MOTOR
correspond with the switch
orientation, turn power off.
Consult a licensed electrician to
switch the red and black
wires from the motor to the switch.
M12
Do not wire motors in parallel without
Connector
written permission from Draper.
W B R G
Control
Switch
Single Gang
B
Box (by others)
Dashed Wiring
by Electrician
110-120V Line
Controls & System Overview
Sonesse 485 120VAC Motors
Bus Power
Supply
LAN
BUS IN
RS485 RS485
110VAC 110VAC
Motor Motor
M12
Connectors
110-120V Line 110-120V Line
Data Cable Pin-Out - RJ45 Connector
1 - DATA + (ORANGE/WHITE)
2 - DATA - (ORANGE)
3 - N/A (GREEN/WHITE)
4 - POWER + (BLUE)
5 - POWER + (BLUE/WHITE)
6 - N/A (GREEN)
7 - GROUND - (BROWN/WHITE)
8 - GROUND - (BROWN)
®
(Coupled)
(Continued)
Controls & System Overview
Sonesse RTS 120VAC Motors
MOTOR
B W G
110-120V Line
110V
Outlet
Data Hub
BUS OUT
to next
DATA HUB
STOP
SDN DecoFlex
Keypad
Data Cable
with RJ45
Connector
Dashed Wiring
by Electrician
RTS
120V
M12 Connector
Telis 1
RF Remote
STOP
DecoFlex
Wire Free Keypad
Dashed Wiring
by Electrician
page 8 of 10
M12 Connector for 4-Wire Motors
To
Motor
4 - GREEN
12"
30.5 cm
Standard
1 - BLACK 2 - WHITE 2 - WHITE 2 - WHITE
Ø 0.61" 15.5 mm
1 - BLACK 2 - WHITE 2 - WHITE 2 - WHITE
60"
1.5 m
Standard
4 - GREEN
To Switch
& 120VAC
W B R G
M12 Connector for 3-Wire Motors
To
Motor
1 - BLACK
12"
30.5 cm
Standard
4 - GREEN
3 - NOT USED
Ø 0.61" 15.5 mm
4 - GREEN 3 - NOT USED
60"
1.5 m
1 - BLACK 2 - WHITE 2 - WHITE 2 - WHITE
Standard
To Switch
& 120VAC
W B G
3 - RED
3 - RED
2 - WHITE 2 - WHITE 2 - WHITE
