Draper FlexShade ZIP XL Instructions Manual

FlexShade ZIP XL
®
XL exterior shading system, ZIP detail creates weather/shading barrier that
protects against wind, sun, snow, and insects to maintain a comfortable space

Overview - Components

E N D
Curved headbox shown.
Angled available.
C A
P
SIDE
CHANNEL
Contents
Overview - Components .......................................................................................1
PLEASE READ - Important Installation, Safety,
Cleaning and Maintenance Information ...............................2
Section 1 - Site Preparation ................................................................................3
Section 2 - Mounting Headbox with Brackets ..................................................3
Section 3 - Mounting Headbox in a Recessed Pocket ....................................4
Section 4 - Installing Side Channels: Preparation ...........................................4
Section 5 - Attaching Side Channels to Headbox ............................................5
Section 6 - Mounting Side Channels Into Recessed Pocket .........................6
INSTRUCTIONS
INSTALLATION & OPERATION
SIDE
CHANNEL
Scan code with your
smartphone to view a playlist
of FlexShade ZIP installation
®
videos. These videos do not
replace the written instructions,
but offer valuable help.
Section 7 - Channel Adaptors .............................................................................6
Section 8 - Limit Setting: RTS Obstacle Detection Motors ............................7
Section 9 - Limit Setting: Standard and Quiet Motors ....................................8
Section 10 - Complete Electrical Connection ..................................................8
Section 11 - Hem Bar Liner ..................................................................................9
Section 12 - Anti-Insect Brush Seals .................................................................9
Section 13 - Cable Exit..........................................................................................9
Section 14 - Dimensions.....................................................................................10
Section 15 - Component Dimensions ..............................................................11
If you have any difficulties installing or servicing your
FlexShade ZIP XL, call your dealer or Draper, Inc.
Draper, Inc. | 411 S. Pearl St. Spiceland, IN 47385
draperinc.com | 765.987.7999 | 800.238.7999
© 2021 All Rights Reserved
PERSONNEL REQUIRED
1 2
TOOLS REQUIRED
TAPE MEASURE
PENCIL
LEVEL
LASER LEVEL
POWER DRILL
WIRE STRIPPERS
HARDWARE PLIERS
(by others)
CRIMPING TOOL HEX WRENCH
CAUTION
Read and understand
all warnings before
beginning installation.
|
FORM: FS_ZIPXL_Inst20
