8 Alarm Status

4.1.2 Modules 9-24: Operation Mode Configuration

Module Name
Pulse Mode
9 Count
Pulse Mode
10 Volume
11 Pulse Mode Units
Pulse Mode Pulse
12 Width
Batch Mode
13 Volume
14 Batch Mode Time
15 Batch Mode Units
Batch Mode Pulse
16 Width
Batch Mode
17 Accumulate
Analog Mode P1
18 Flowrate
Analog Mode P1
19 Current
Analog Mode P2
20 Flowrate
Analog Mode P2
21 Current
Cycle Timer Mode
22 Status
Cycle Timer
23 Duration
PROFIBUS SOFTWARE DEFINITION
Returned as a bitmask with a high bit to
indicate the status of each item:
Bit 0 - Global Alarm
Bit 1 - User Alarm
Bit 2 - Tank Empty
Bit 3 - Tank Low
Bit 4 - Internal System Error
Bit 5 - Motor Stall
Bit 6 - Analog Loss of Signal
Bit 7 - Analog Overrange
Bit 8 - Motor Homing Error
Bit 9 - Pulse Signal not Present
Bit 10 - Pulse Signal Overrange
Description
Range of 1-10,000.
XXXXX.XX mL. Range is 0 to 1000000.
Enumeration (0=Small, 1=Large). Large will
use Gallons or Liters based on global units
setting. Small will use fl oz. or mL based on
global units setting.
msec. The valid range is 4 - 60 in increments
of 4.
XXXXX.XX mL. The valid range is 0 to
1000000.
Seconds. Range is 1-86400.
Enumeration (0=Small, 1=Large). Large will
use Gallons or Liters based on global units
setting. Small will use fl oz. or mL based on
global units setting.
msec. Range is 4 - 60 in increments of 4.
Enumeration (0 = Off, 1 = On).
XX.XX in the current units (i.e. GPH/LPH). The
range is 0-9999.
XX.X mA. Range is 0.0-20.0.
XX.XX in the current units (i.e. GPH/LPH).
Range is 0-9999.
XX.X mA. Range is 0-200.
Minutes. Range is 1-1439. The Cycle Time is
the period of active pumping.
Minutes. Range is 1-1439. The Duration is the
inactive period.
Output UINT16
Data
Direction Type
Input/Output UINT16
Input/Output UINT32
Input/Output BOOL
Input/Output UINT8
Input/Output UINT32
Input/Output UINT32
Input/Output BOOL
Input/Output UINT8
Input/Output BOOL
Input/Output UINT16
Input/Output UINT8
Input/Output UINT16
Input/Output UINT8
Input/Output UINT16
Input/Output UINT16
