LMI Excel XR Series Manual page 14

Enumeration for the pump output code. The
output code is associated with the maximum flow
rate of the pump:
2: Output Code 2 - 5.6 GPH (21.2 l/h) 175 psi
(12.0 bar)
3: Output Code 3 - 14.0 GPH (53.0 l/h) 75 psi (5.0
bar)
4: Output Code 4 - 18.0 GPH (68.1 l/h) 50 psi (3.5
70 Model ID bar)
Enumeration
1=English
2=French
3=Portuguese
4=Spanish
71 Language 5=Chinese
Current
72 Flow Rate Integer representing XX.XX GPH/LPH format.
Flow
73 Percentage Integer representing XXX.XX%.
Analog Input
74 1 Integer representing XX.X mA.
Analog Input
75 2 Integer representing XX.X mA.
Analog
76 Output Integer representing XX.X mA.
Totalizer
User
77 Strokes Integer representing number of strokes.
Totalizer
User Integer representing Gal or L depending on
78 Volume current unit setting.
Totalizer
79 User Hours Integer representing number of hours.
Totalizer
User Power
80 Cycles Integer representing the number of Power Cycles.
Totalizer
81 Unit Strokes Integer representing number of strokes.
Totalizer Integer representing Gal or L depending on
82 Unit Volume current unit setting.
Totalizer
83 Unit Hours Integer representing number of hours.
Totalizer
Unit Power
84 Cycles Integer representing the number of Power Cycles.
This is the maximum flow rate of the pump based
Calibrated on the calibration and is stored as an integer
85 Volume representing XX.XX GPH/LPH.
Batch Mode
Remaining Integer representing Gal or L depending on
86 Volume current unit setting.
Batch Mode
Remaining
87 Dosing Time Integer representing number of seconds.
PROFIBUS SOFTWARE DEFINITION
Output UINT8
Output UINT8
Output UINT16
Output UINT16
Output UINT16
Output UINT16
Output UINT16
Output UINT32
Output UINT64
Output UINT32
Output UINT16
Output UINT32
Output UINT64
Output UINT32
Output UINT16
Output UINT16
Output UINT32
Output UINT32
