4.1.4 Modules 43-57: Input/Output Configuration

Module Name
Digital Input 1
43 Config
Digital Input 1
44 State
Digital Input 2
45 Config
Digital Input 2
46 State
Digital Input 3
47 Config
Digital Input 3
48 State
Digital Input 4
49 Config
Digital Input 4
50 State
Analog Input 1
51 Config
Analog Input 2
52 Config
PROFIBUS SOFTWARE DEFINITION
Description
Enumeration with a range 0-5. The
enumeration is as follows:
0: Digital Input = Disabled
1: Digital Input = RemoteOnOff
2: Digital Input = FloatSwitch_Empty
3: Digital Input = FloatSwitch_Low
4: Digital Input = RemoteIntExtMode
5: Digital Input = PacingPulse
Enumeration (0=NO - Normally Open, 1=NC
- Normally Closed).
Enumeration with a range 0-5. The
enumeration is as follows:
0: Digital Input = Disabled
1: Digital Input = RemoteOnOff
2: Digital Input = FloatSwitch_Empty
3: Digital Input = FloatSwitch_Low
4: Digital Input = RemoteIntExtMode
5: Digital Input = PacingPulse
Enumeration (0=NO - Normally Open, 1=NC
- Normally Closed).
Enumeration with a range 0-5. The
enumeration is as follows:
0: Digital Input = Disabled
1: Digital Input = RemoteOnOff
2: Digital Input = FloatSwitch_Empty
3: Digital Input = FloatSwitch_Low
4: Digital Input = RemoteIntExtMode
5: Digital Input = PacingPulse
Enumeration (0=NO - Normally Open, 1=NC
- Normally Closed).
Enumeration with a range 0-5. The
enumeration is as follows:
0: Digital Input = Disabled
1: Digital Input = RemoteOnOff
2: Digital Input = FloatSwitch_Empty
3: Digital Input = FloatSwitch_Low
4: Digital Input = RemoteIntExtMode
5: Digital Input = PacingPulse
Enumeration (0=NO - Normally Open, 1=NC
- Normally Closed).
Enumeration with a range 0-2. The
enumeration is as follows:
0: Analog Input = Disabled
1: Analog Input = Pacing
2: Analog Input = Level
Enumeration with a range 0-2. The
enumeration is as follows:
0: Analog Input = Disabled
1: Analog Input = Pacing
2: Analog Input = Level
Data
Direction Type
Input/Output UINT8
Input/Output BOOL
Input/Output UINT8
Input/Output BOOL
Input/Output UINT8
Input/Output BOOL
Input/Output UINT8
Input/Output BOOL
Input/Output UINT8
Input/Output UINT8
