Parts List - Quadratec QR3 Installation Manual

Installation Hardware:
E
Driver
Side C
G
J H

PARTS LIST:

Driver (Left) Side Tube Step
Passenger (Right) Side Tube Step
Mounting Brackets: (length)
A) Driver (Left) Front: (medium)
B) Pass (Right) Front: (medium)
C) Driver (Left) Center (4dr): (long) QTY 1
D) Pass (Right) Center (4dr): (long) QTY 1
E) Driver (Left) Rear: (short)
F) Pass (Right) Rear: (short)
Nut Plates:
G) 10mm Length: QTY 6 (4dr) QTY 4 (2dr)
Hex Bolts:
H) 8mm x 35mm:QTY 6 (4dr) QTY 4 (2dr)
I) 8mm x 25mm: QTY 12 (4dr) QTY 8 (2dr)
J) 10mm x 35mm:QTY 6 (4dr) QTY 4 (2dr)
Brackets will be marked with positions, DF = Drivers Front, DC = Driv-
ers Center & DR = Drivers Rear, same will apply to the passenger side
brackets. Two Door Models will only use a Front and Rear Bracket.
You must remove factory installed "Rock Rails", side steps or running
boards before installation of your new Side Tube Steps.
This instruction sheet covers the installation of both the 3" round
tube steps as well as the 4" Oval Tube steps for 2 & 4 Door Jeep
Wrangler. Pictures in this instruction booklet may not show your
specific model but installation is identical for both tube diameters.
A
B
I R S K
Flat Washers:
QTY 1 K) 10mm ID x 34mm OD x 3mm:
QTY 1
L) 8mm x 24mm OD x 2mm:
QTY 1 M) 8mm x 28mm OD x 3mm:
QTY 1
N) 6mm ID x 18mm OD x 1.6mm:
QTY 1
QTY 1 Lock Washers:
O) 8mm:
P) 10mm:
Button Head Bolts:
R) 6mm x 25mm:QTY 12 (4dr) QTY 8 (2dr)
Nylon Lock Nuts:
S) 6mm:
