QuadraTop
Installation Manual: for 2003-2006 LJ Wrangler #11113.1035
Throughout this
instruction sheet pictures
of a TJ Wrangler are used.
Install on LJ Wrangler is
the same.
PARTS & REQUIRED TOOLS
REQUIRED TOOLS:
Safety
Glasses
Phillips Head Screwdriver
T30 Torx Head and Driver
Drill Motor
1/4" Drill Bit
3/32" Drill Bit
Large towel or Blanket
AdventureTop Conversion Soft Top
®
PART LIST:
A)Top Deck
B)Drivers Side Quarter Window
C)Passenger Side Quarter Window QTY 1
D)Rear Window
E)Side Tubes
F)Door Surround Brackets
G)Center Bow
IMPORTANT: This Top requires the
QTY 1
use of your factory Soft top
QTY 1
hardware including door surrounds
and Tailgate bar. This kit does not
QTY 1
include these components.
QTY 2
QTY 2
QTY 2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Quadratec QuadraTop
Summary of Contents for Quadratec QuadraTop
- Page 1 QuadraTop AdventureTop Conversion Soft Top ® Installation Manual: for 2003-2006 LJ Wrangler #11113.1035 Throughout this instruction sheet pictures of a TJ Wrangler are used. Install on LJ Wrangler is the same. PARTS & REQUIRED TOOLS REQUIRED TOOLS: PART LIST: Safety...
- Page 2 A FEW WORDS ABOUT PRODUCT SAFETY: Your QuadraTop® Soft top is intended to enhance the utility and enjoyment of your off-road capable vehicle. Follow safety information and installation recommendations. Throughout these instructions is important safety information that is generally preceded by one of three signal words indicating the relative risk of injury, property damage or adverse consequence.
- Page 3 Step 1 Factory Hardware Requirement: This product is designed to fit over your original factory soft top hardware, Door Surrounds, Windshield header and fac tory soft upper metal door frames (if applicable).your vehicle. Remove Existing Soft Top Fabric Put on safety glasses. After verifying that you have the correct hardware, remove the existing soft top from the vehicle. This will in- clude removing the existing soft top fabric from the front windshield header.
- Page 4 Step 3 FIG 3 Preparation for Installing Fabric Only Replacement Top: Install Top Fabric on the Front Windshield Channel Place the soft top fabric on the ground (on top of a large blanket or towel) with the underside facing up and the front of the fabric facing you (FIG 3).
- Page 5 Step 5 FIG 13 FIG 14 FIG 15 FIG 16 FIG 17 This step requires you to install the center bow/over door bracket on top of the factory door surrounds (FIG 13). Befo re you install these brackets, you will need to remove the factory over door “pin” from the door surround. This can be done with a Phillips head screw driver.
- Page 6 Step 7 FIG 24 FIG 26 FIG 24A FIG 25 FIG 24A Installing the Center Bow to the Door Surrounds Locate the Center Bow assembly with the preinstalled quick release knuckles on the ends. With the top folded back as shown in FIG23, locate the bottom rear-most brac ket hole (FIG24) and slip the rear bow through the webbing strap loop located on corner of the top deck (Fig 24A).
- Page 7 Step 8A FIG 38 FIG 36 FIG 37 FIG 35 FIG 40 FIG 39 Installing the Quarter and Rear Windows to the Top Deck To ensure the top is centered on the vehicle you will be installing the two quarter windows and the rear window to the top deck and to each other before securing it to the vehicle body.
- Page 8 When removing the quarter windows from the Top deck, make sure the zipper is NOTICE completely out of the "zipper box" before removing the window. FIG 46a FIG 46b Step 9 FIG 48 FIG 47 FIG 50 FIG 49 FIG 54 FIG 53 FIG 51 FIG 52...
- Page 9 Step 10 FIG 55 FIG 56 FIG 57 FIG 58 Secure the Over Door Attachments Locate the two plastic strips sewn to the sides of the top above each door (FIG55). Starting with the front strips, slip the strips into the channel in the door surround above the door opening (FIGs 56 & 57). Secure the strips on each side of the vehicle.
- Page 10 FIG 64 FIG 65 FIG 66 FIG 67 FIG 68 FIG 69 Unlatch your over door Attachments from the door Surrounds. (FIG64)Unlatch the front header from the windshield (FIG65). Pushing up from the middle, fold back the top. (FIG66). Make sure the center bow is secured through the sewn inside webbing strap.
- Page 11 3 years from date of initial retail sale. Quadratec reserves the rights to: (a.) require invoice or other proof your accessory is within the terms of thisLimited Warranty as a condition of warranty service and, (b.) make future revisions to this product and Limited Warranty without prior notice or obligation to upgrade your product.
