Technical data
DSWa with 2 pumps:
Type
Pumps
Nominal width of pipework
Nominal width of flushing connector
Connector for relief valve return line
Dimensions (WxHxD) in mm
Pulsation damper
Volume of vacuum cylinder
Max. capacity
Max. operating pressure (25 °C)
Max. operating pressure (40 °C)
Type
Pumps
Nominal width of pipework
Nominal width of flushing connector
Connector for relief valve return line
Dimensions (WxHxD) in mm
Pulsation damper
Volume of vacuum cylinder
Max. capacity
Max. operating pressure (25 °C)
Max. operating pressure (40 °C)
42
SP10
Beta 4/5b, DLTa, GMXa
DN 10
DN 10
DN 10
1000x1400x450
0.09 l
0.5 l
75 l/h
10 bar
6 bar
S220
Sigma/ 2
DN 20
DN 15
DN 15
1600x2000x650
0.36 l
2.5 l
350 l/h
10 bar
6 bar
S110 S115
Sigma/ 1 Sigma/ 1
DN 10 DN 15
DN 10 DN 10
DN 10 DN 10
1200x1600x650
0.36 l 0.36 l
0.5 l 1 l
65 l/h 120 l/h
10 bar 10 bar
6 bar 6 bar
S325 S332
Sigma/ 3 Sigma/ 3
DN 25 DN 32
DN 20 DN 25
DN 20 DN 25
1600x2500x650
0.36 l 0.95 l
2.5 l 5.0 l
365 l/h 1040 l/h
10 bar 8* / 10 bar
* with pulsation damper
option
6 bar 6 bar
S215
Sigma/ 2
DN 15
DN 10
DN 10
0.36 l
1 l
135 l/h
10 bar
6 bar
