LCD

Part Description
2.2" TFT LCD

Character Display (J21)

Part Description
20x2 character display

Debug (X602)

The debug connectors provides a connection point for the emulator to interface with the processor. There are two
debug connectors on the board. The P4 connector is a 0.1" 20 pin connector. The P5 connector is a 0.05" 10 pin
connector. For more information, see
USB ( )
P3
The USB connector provides an interface between the CPA board and a host PC via the
Part Description
USB mini-B
Manufacturer
Adafruit
Manufacturer
Newhaven Display
Debug Interface.
Manufacturer
Hirose
27
Part Number
1480
Part Number
NHD-0220D3Z-FL-GBW-V3
USB to UART
Part Number
UX60SC-MB-5S8
(FT232R).
