Combine two separate office networks into one.
The device in AP Mode connects to one office network
and creates a wireless network. The device in Client Mode connects to the other office
network and the wireless network.
Establish a point-to-point WLAN across a long distance to achieve the
connectivity between two networks and avoid the cabling trouble.
Access Point Laptop/Tablet/Smartphone
Wired Local
Internet
Area Network
Establish wireless network coverage in the campus, community,
industrial park or public place to provide wireless access for users.
With the access to campus wired network or other wired local
area networks, the device in AP Mode provides the wireless access for wireless clients,
such as smart phones, laptops and tablets to connect to the network.
Enrich the access ways of local area network and extend the network
coverage.
1.2
For the device in Client Mode, the most common usage scenario is point-to-point
networking. The device is used to transform wireless signal into wired one.
Access Point Client
LAN: 192.168.0.254 LAN: 192.168.0.2
Switch Switch
5
