TP-Link Pharos Series User Manual page 68

IPv6 Enable or disable the IPv6 function. If the IPv6 function is enabled, the
device will obtain a WAN IPv6 address. Select a method for the device to
obtain the WAN IPv6 address according to the information provided by
your ISP.
•
• SLAAC
•
MTU Size Specify the MTU size. The normal MTU (Maximum Transmission Unit)
value for most Ethernet networks is 1500 Bytes. For some ISPs you need
to modify the MTU. But this is rarely required, and should not be done
unless you are sure it is necessary for your ISP connection. This number
should be an integer between 576 and 2026.
WAN MAC Specify the WAN MAC address. This field displays the current MAC
Address
address of the WAN port. If your ISP requires that you register the MAC
address, enter the correct MAC address into this field. The format for
the MAC Address is XX-XX-XX-XX-XX-XX (X is any hexadecimal digit).
Click Restore Factory MAC to restore the MAC address of WAN port to
the factory default value.
Your PC's MAC Displays the MAC address of the PC that is managing the device. Some
Address
ISPs require that you should register the MAC address of your PC. If the
MAC address is required, click Clone PC's MAC to set the WAN MAC
address the same as your management PC's MAC.
Click Apply , then click Save .
Select static and enter the WAN IPv6 address, IPv6 netmask, IPv6
gateway, primary DNS and secondary DNS provided by your ISP.
Select SLAAC and the device will obtain the WAN IPv6 address
automatically.
Select DHCPv6 and the device will obtain the WAN IPv6 address
automatically.
64
