TP-Link Pharos Series User Manual page 87

Go to the
Control function.
Total Ingress Specify the upper bandwidth for receiving packets from the WAN port.
Bandwidth
The maximum value is 100,000kbps.
Total Egress Specify the upper bandwidth for sending packets from the WAN port.
Bandwidth
The maximum value is 100,000kbps.
Click Add and specify the following parameters.
Enable Enable or disable the desired entry.
IP Range Enter the IP Range of the target hosts which need to be controlled of
bandwidth, for example 192.168.0.12-192.168.0.25.
Port Range Enter the Port Range through which the target hosts visit external server,
for example 1-63258.
Protocol Choose one of the protocols used for this application: TCP, UDP, or TCP/
UDP.
Ingress Min Specify the minimum ingress bandwidth for the desired entry.
(kbps)
Ingress Max Specify the maximum ingress bandwidth for the desired entry.
(kbps)
Egress Min Specify the minimum egress bandwidth for the desired entry.
(kbps)
page. In the
83
section, enable the Bandwidth
