RX Signal
Noise Floor
CCQ
Last IP
TX/RX Rate
TX/RX Bit Rate
TX/RX Packets
TX/RX Packets
Rate, pps
Bytes
Transmitted
Bytes Received
Negotiated Rate
Last Signal, dBm
Click the IP Address of a station to access the web management page of the station.
Displays the signal strength of the wireless network.
Displays the noise strength of the wireless network.
Displays the wireless Client Connection Quality (CCQ). CCQ refers to the
ratio of effective transmission bandwidth and the actual total bandwidth.
It reflects the quality of the actual link. A larger value means a better
utilization of the bandwidth.
Displays the IP address of the station.
Displays the negotiated rates of the transmitted and received packets. TX
means that the device transmits data to the station, while RX means that
the device receives data from the station.
Displays the data rates of the last transmitted and received packets. TX
means that the device transmits data to the station, while RX means that
the device receives data from the station.
Displays the total number of the transmitted and received packets. TX
means that the device transmits data to the station, while RX means that
the device receives data from the station.
Displays the packet rates of the transmitted and received packets. TX
means that the device transmits data to the station, while RX means that
the device receives data from the station.
Displays the total amount of data which the device transmits to the
station.
Displays the total amount of data which the device receives from the
station.
Displays the possible negotiated rates of the packets which the device
receives from the station.
Displays the signal strength of the last packet which the device receives
from the station at the corresponding negotiated rate.
48
