1 Installing the Router

Chapter 1 Installing the Router

1.1 Introduction

The ATLAS 50 aims at meeting the voice, video and data needs of small-sized companies and offices. It is a modu-
lar device incorporating encryption hardware and designed with network convergence in mind, as it supports IP Tele-
phony and the possibility to encode video. Teldat presents the ATLAS 50 as a perfect solution for wireless techno-
logy, both for the local network (with wireless access point functionality) and for the wide area network, as this device
supports the following interface cards: GSM, GPRS, EDGE, UMTS, HSDPA, CDMA2000, EV-DO and WiMAX
This manual shows you how to connect and install this device.
ATLAS 50 front panel
Fig. 1:

1.2 Connections

Caution
Before connecting the router, please read the following instructions carefully.
Workplace Conditions. Main Characteristics
• Excessive cold and heat should be avoided, as should humidity and dust.
• Direct exposure to sunlight should be avoided as well as other heat sources. The device should not be placed
amongst papers, magazines or other elements that could hinder natural air circulation.
• The device should not be placed very close to strong electromagnetic fields such as speakers, engines, etc.
• Knocks and/or strong vibrations should be avoided during transport, operation and storage.
Warning
The electric current in power cables, telephone lines and communication cables is dangerous. To pre-
vent electric shocks, before installing, handling or opening the equipment covers, connect and discon-
nect the cables as follows:
To Connect
Turn the device's power supply OFF
Check that the power supply is not connected to either
2
To Disconnect
Turn the switch OFF
Disconnect the power supply from the main electricity
Teldat S.A.
ATLAS 50
