1 Installing the Router

1.5.1 Procedure to install PMC cards

(1) Switch off the device and remove the cables (as described in the section on connection in this manual).
(2) Remove the device from the workplace and place it in a stable, safe place where it can be easily accessed and
handled. Open up the device. To do this you need to remove the upper cover, which is secured through two
screws located on the underside of the device.
(3) Once the screws have been removed, slide the cover towards the front panel and then remove it by lifting it.
Place it in a safe place.
(4) Find the place where the PMC board needs to be located (labeled as SLOT#1 in the device). This slot has a set
of elevated connectors with gold contacts and a pair of securing screws.
(5) Remove the blind cover from the spot. This cover is located on the rear panel. Push this out.
(6) Place the PMC board, securing posts over the securing screws. Secure these firmly.
(7) Place the PMC card in the slot so that this firstly adjusts to the space on the device rear panel and subsequently
to the two PMC connections. This operation must be carried out carefully, without forcing any piece or part of
the device. Check that the board is clearly settled over the PMC connectors.
(8) Screw the PMC board to the posts using two screws with their corresponding washers. Firmly tighten the
screws without damaging the board.
(9) Close the device with the cover. To do this, place the device upside down adjusting the three slots on the under-
side in the device's front panel and subsequently adjust the cover. Secure the cover with the screws.
(10) Connect and switch on the device (as explained in the connection section). Should you detect any problems,
switch off the device and make sure that the above steps have been carried out correctly. If the problem per-
sists, please contact your usual supplier.
(11) Connect a terminal to the console and check that the device detects the PMC board.
**************************************************
******************* Router Teldat ****************
**************************************************
BOOT CODE VERSION: 01.06
gzip Dec 28 2005 09:54:11
P.C.B.: A0
START FROM FLASH
BIOS CODE DUMP....................
BIOS DATA DUMP...
End of BIOS dump
Boot-stack used: 0x00000C38
Boot-stack free: 0x000013C8
==========================================================
BIOS TELDAT
==========================================================
BIOS CODE VERSION: 01.06
CLK=262144 KHz
Date: 01/12/06, Thursday
SDRAM size: 32 Megabytes
BANK 0: 32 Megabytes (detected)
Caches: ON
FLASH: 64 Mb.
NVRAM: 128 Kb.
EEPROM: 2048 Bytes.
DPRAM: 8192 Bytes.
ISAC
10
Jan 2 2006 10:22:22
MASK:0C10 Microcode:00E1
BUSCLK=65536 KHz
Time: 12:40:13
Write-Back
(c)Teldat
PCICLK=65536 KHz L0
