CABLE
* Depending on the model
Configuration Interface
TERMINAL LOCAL TERMINAL V.24 9.600-8-N-1- without flow control.
CONNECTOR
Power Supply
INPUT VOLTAGE
INPUT CURRENT
MAXIMUM POWER
External Power Source
INPUT VOLTAGE
INPUT CURRENT
INPUT FREQUENCY
MAXIMUM POWER
Dimensions and Weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
Environmental Specifications
AMBIENT TEMPERATURE
RELATIVE HUMIDITY
ATLAS 50
Length<3m
RJ45 female, on the rear panel of the device.
+5 V,+12 V,-12 V DC
5 A (to +5 V DC) , 1 A (to +12 V DC) and 0.1 A (to -12 V DC)
30 W
100-240 V AC
1 A
50-60 Hz
45 VA
Desktop
220 x 220 x 30 mm
1 kg
ON: 5º to 45 ºC. OFF: -20º to 60 ºC.
ON: 8 % to 85 %. OFF: 5 % to 90 %.
Technical Information
