Husqvarna Automower Solar Hybrid Technical Manual page 59

Example number 6
In this example the charging station is placed by an island. The easiest way to reach Area 1 is with the help
of the Exit angles function.
The working area contains many islands, which results in long search times. By increasing the corridor
width for the boundary wire, the search times are reduced, as the mower will then run past unnecessary
passages. However this does suggest a risk of tracks forming. Consequently, a guide wire is
recommended.
Fully approved
Follow loop Boundary wire
Delay 20 minutes
Corridor width 10
Example number 7
In this example Automower, with the help of the settings, will reach the entire working area.
Fully approved
Follow loop Boundary wire
Delay 11 minutes
Corridor width 6
3. INSTALLATION
3m (10ft)
4m (13ft)
1
Guide wire
7 minutes
6
1
3m (10ft)
3m (10ft)
2
Guide wire
7 minutes
6
3m (10ft)
6
10
2
Exit angles
Start angle 1 – End angle 1 (2)
Start angle 2 – End angle 2 (1)
Proportion first
Follow loop out Area 1
Direction Left
Distance 30 metres (100 ft)
Proportion 20%
3012-630
Area 1, 2
90° and 200°
240° and 270°
40 %
3012-633
Area 2
Left
15 metres (50 ft)
40%
English - 59
