ALERT – Loop Power Out of Range
Description:
The VECTOR V1100 is configured for Loop Power Mode and the current on the loop power
connection is outside of the allowable VECTOR V1100 operating range.
Corrective Action:
Correct the loop power supply.
Timestamps:
Start: Set when the alert is first detected.
Stop: Set when the alert state goes away.
ALERT – Temperature Out of Range
Description:
The electronics temperature inside of the VECTOR V1100 is outside of the allowable VECTOR
V1100 operating range.
Corrective Action:
Ensure that the VECTOR V1100 is installed in an environment within its environmental
operating range.
Timestamps:
Start: Set when the alert is first detected.
Stop: Set when the alert state goes away.
ALERT – Power Mode Misconfigured
Description:
The power mode detected on the inputs for the VECTOR V1100 currently does not match the
power mode configuration settings.
Corrective Action:
Check the Adapter Power mode setting to ensure it is the same as how the VECTOR V1100 is
wired.
Timestamps:
Start: Set when the alert is first detected.
Stop: Set when the alert state goes away.
