B. Set the Power Configuration for the VECTOR V1100:
1. From the main DD screen, select Configure... (In Simatic PDM, select Configure... from the
Device menu at the top of the screen).
2. Select Guided Setup...
3. Select Configure Power Mode...
4. Follow the on screen instructions and select the proper power configuration for the
application.
C. Configure Burst settings:
1. From the main DD screen, select Configure... (In Simatic PDM, select Configure... from the
Device menu at the top of the screen).
2. Select Manual Setup... Burst Settings...
3. Set the Automatic Burst Mode to the desired update rate (recommended) or set this to
disabled. If not using the Automatic Burst Mode, manually set the burst mode
configuration for each Burst Message.
4. Transfer the updated information to the VECTOR V1100 by clicking on the Send or
Transfer button.
D. Configure Wireless HART network settings:
1. From the main DD screen, select Configure... (In Simatic PDM, select Configure... from the
Device menu at the top of the screen).
2. Select Guided Setup...
3. Select Join Device to Network...
4. Follow the on screen instructions and enter in the wireless HART network ID and join key.
5. After accepting the settings, the VECTOR V1100 attempts to join the network if the wireless
HART gateway is in range.
Sub-devices must be detected before configuring the manual
NOTE
Burst Mode configuration.
