600-D100/X4/A, Assy, Gear Box Complete, W/O Armature (Parts List) - Demtech Pro-X5 600-0105/X5/A Operator's Manual

Rev. A: January 2015
17 STOCK
16 STOCK
15 600-D31K
14
600-D31EX
13 600-D30/S/X4
12 600-D30.0
11 600-D26
10 600-D25
9 600-D24EX
8 600-D24/O
7 600-D17
6 600-D15
5 600-D12
4 600-D11
3 600-D02/S
2 600-D01EX
1 600-50
ITEM PART NUMBER
10.12.

600-D100/X4/A, Assy, Gear Box Complete, w/o Armature (Parts List)

600-Manual_Pro-X5 RA.docx
SCREW, M4 X .7 X 20mm LONG, SOCKET HEAD
CAP, 18-8 STAINLESS STEEL
PIN, DOWEL, 1/8" OD X 1/2" LONG, 18-8
STAINLESS STEEL
KEY, LARGE GEAR TO OUTPUT SHAFT
KEY, OUTPUT SHAFT TO EXTRUSION SCREW
SEAL, OUTPUT SHAFT, GEAR BOX, PRO-X4
SHAFT, DRIVE
DISC, BEARING PLATE, VENTILATION
BEARING, GEARBOX
CASING, DRILL MOTOR, GEAR
O-RING, GEARBOX
BEARING, DRIVE SHAFT
ASSEMBLY, PINION / SPUR GEAR SET
GEAR, DRIVE SHAFT, LARGE
ASSEMBLY, PINION / HELICAL GEAR SET
SEAL, ARMATURE
PLATE, GEAR CASING, BEARING
SNAP RING, THRUST BEARING & DRIVE SHAFT
DESCRIPTION
PARTS LIST
Pro-X5 Operator's Manual
3
2
1
1
1
1
1
5
1
1
1
1
1
1
1
1
1
QTY
Page 32
