b. Remove the Teflon Shoe Assembly from the Nozzle, DEMTECH part number 600-20/X4.
Due to melted plastic material buildup, removal of the Shoe may require strong twisting
motion clockwise and counterclockwise and significant pulling force to remove (see Figure
7.5). There are several different Teflon Shoe Assemblies available; those shown in Figure
7.5 are DEMTECH part numbers TS-600-60/A (on the right) and TS-600-60-AEG/A (on
the left). Please go to www.demtech.com for a complete listing of Teflon Shoe Assemblies
and other available Pro-X5 accessories.
600-20/X4
Figure 7.5
