Product overview
Two-channel, digital input terminals, 24 V
The KL1002 and KL1012 digital input terminals acquire the binary control signals from the process level and
transmit them, in an electrically isolated form, to the higher-level automation unit. The KL1002 and KL1012
versions have input filters of different speeds. The Bus Terminals contain two channels that indicate their
signal state by means of light emitting diodes.
2.2.1 KL1002, KL1012 – Technical data
Technical data
Connection technology
Specification
Number of counters
Nominal voltage
Signal voltage '0'
Signal voltage '1'
Input filter
Input current
Current consumption from K-bus typically 3 mA
Electrical isolation
Bit width in process image
Configuration
Weight approx.
Permissible ambient temperature
during operation
Permissible ambient temperature
during storage
Permissible relative humidity
Vibration / shock resistance
EMC immunity / emission
Installation position
Protection class
Pluggable wiring
Approvals
10
DC
KL1002, KS1002
4-wire
EN 61131-2, type 1/3
2
24 V (-15 %/+20 %)
DC
-3 V to 5 V (EN 61131-2, type 1)
15 V to 30 V (EN 61131-2, type 1)
3 ms
typically 5 mA (EN 61131-2, type 1)
500 V (K-bus / field voltage)
2 input bits
no address or configuration settings required
50 g
-25°C ... +60°C (extended temperature range)
-40°C ... +85°C
95 %, no condensation
according to EN 60068-2-6 / EN 60068-2-27, refer also to
Installation instructions for enhanced mechanical load capacity [} 35]
conforms to EN 61000-6-2 / EN 61000-6-4
variable
IP20
for all KSxxxx terminals
CE, cULus, ATEX [} 41], GL
Version: 1.0.0
KL1012, KS1012
0.2 ms
KL1xxx
