LED status indicators
The dataFEED edgeGate is equipped with four LEDs on its front side:
PWR
RUN
ERR
SYS
The LEDs may be on permanently or flash in different colors and frequencies. We use the
following symbols:
Symbol
Copyright 2017 Softing Industrial Automation GmbH
stands for power supply (permanently green if the 24V DC power supply is
ok)
stands for running
stands for error
stands for system
Color
none
red
green
red
green
Chapter 4 - LED status indicators
Lighting
off
permanent
permanent
flashing
flashing
