Instructions
95-8549
UV Flame Detector
X2200
8.3
Rev: 6/10
95-8549

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Det-Tronics X2200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for UTC Fire and Security Det-Tronics X2200

Summary of Contents for UTC Fire and Security Det-Tronics X2200

  • Page 1 Instructions 95-8549 UV Flame Detector X2200 Rev: 6/10 95-8549...

  • Page 2: Table Of Contents

    Table of Contents DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 TROUBLESHOOTING .

  • Page 3: Description

    INSTRUCTIONS UV Flame Detector X2200 IMPORTANT Be sure to read and understand the entire instruction manual before installing or operating the flame detection system. Any deviation from the recommendations in this manual may impair system performance and compromise safety. ATTENTION The X2200 includes the Automatic Optical Integrity ( o i ) feature —...

  • Page 4: Led

    The Auxiliary relay has normally open / normally Table 2—Detector Status Indicator closed contacts, and is configurable for energized or Detector Status LED Indicator de-energized operation, and latching or non-latching operation. Power On/Normal Auto Green (no fault or fire alarm) 0 to 20 mA Output Green, flashing on for 0.5 sec.

  • Page 5: Communication

    CAUTION INTEGRAL WIRING COMPARTMENT These tests require disabling of all extinguishing All external wiring to the device is connected within devices to avoid release resulting from a the integral junction box. The screw terminals accept successful test. wiring from 14 to 24 AWG. The detector is furnished with four conduit entries, with either 3/4 inch NPT or 25 mm The magnetic o i test is performed by placing a magnet by threads.

  • Page 6: General Application Information

    GENERAL APPLICATION FACTORS INHIBITING DETECTOR RESPONSE INFORMATION Windows RESPONSE CHARACTERISTICS Glass and Plexiglas windows significantly attenuate UV Response is dependent on distance, type of fuel, radiation and must not be located between the detector temperature of the fuel, and time required for the fire to and a potential flame source.

  • Page 7: Important Safety Notes

    IMPORTANT SAFETY NOTES Table 3 UV Absorbing Gases and Vapors WARNING Do not open the detector assembly in a hazardous The following is a partial list of compounds that exhibit area when power is applied. The detector contains significant UV absorption characteristics. These are limited serviceable components and should never also usually hazardous vapors.

  • Page 8: Installation

    INSTALLATION NOTE The recommended lubricant for threads and CENTER AXIS OF DETECTOR O-rings is a silicone free grease (part number FIELD OF VIEW 005003-001) available from Detector Electronics. Under no circumstances should a lubricant containing silicone be used. INCORRECT DETECTOR POSITIONING Detectors should be positioned to provide the best unobstructed view of the area to be protected.

  • Page 9: Wiring Procedure

    If conduit is used, we recommend installing drains, NOTE according to local codes, at water collection points Refer to “Power Consumption” in the “Specifications” to automatically drain accumulated moisture. It is section of this manual. also recommended to install at least one breather, The use of shielded cable is required to protect against according to local codes, at upper locations to provide interference caused by EMI and RFI.

  • Page 10: Eol Resistors

    Relay and 0-20 mA Output Models EOL RESISTORS (Not Used with EQP Model) Follow the instructions below to install the X2200. To ensure that the insulating material of the wiring terminal block will not be affected by the heat generated by EOL 1.
  • Page 11 X2200 DETECTOR FIRE ALARM PANEL 4-20 mA + 4-20 mA – SPARE 4-20 mA + REF 4-20 mA – REF SPARE COM FIRE 2 COM AUX COM FIRE N.O. FIRE 2 N.O. AUX N.O. FIRE E.O.L. DEVICE 4 N.C. FIRE 2 N.C.
  • Page 12 X2200 DETECTOR X2200 DETECTOR 4-20 mA + 4-20 mA – 600 Ω MAX 4-20 mA + 600 Ω MAX 4-20 mA – AT 24 VDC AT 24 VDC 4-20 mA – REF 4-20 mA + REF – – 4 TO 20 mA 4 TO 20 mA 24 VDC 24 VDC...
  • Page 13 EQP Model 5. Check all field wiring to be sure that the proper connections have been made. 1. Connect external wires to the appropriate terminals inside the device junction box. (See Figure 13 for 6. Replace the device cover. terminal identification.) 7.
  • Page 14 CH 1 CH 2 CH 3 CH 4 CH 5 CH 6 CH 7 CH 8 RELAY 2 RELAY 3 RELAY 4 RELAY 1 DIGITAL INPUTS RELAY 5 RELAY 6 RELAY 7 RELAY 8 95-8549...

  • Page 15: Setting Device Network Addresses

    ADDRESS SWITCHES SENSOR MODULE REMOVED FROM HOUSING A2191 Figure 15—Location of Address Switches The address number is binary encoded with each switch SETTING DEVICE NETWORK ADDRESSES having a specific binary value with switch 1 being the (EQ and EQP Models Only) LSB (Least Significant Bit).

  • Page 16: Startup Procedure

    STARTUP PROCEDURE Table 4—Current Level Output Troubleshooting Guide Current Level Status Action When installation of the equipment is complete, perform (±0.3 mA) the “Fire Alarm Test” below. 0 mA Power Fault Check system wiring. Cycle power. 1 1 mA General Fault FIRE ALARM TEST Clean windows.

  • Page 17: Maintenance

    MAINTENANCE PLATE REMOVAL 1. Disable any extinguishing equipment that is connected to the unit. IMPORTANT Pe r i o d i c fl a m e p a t h i n s p e c t i o n s a re n o t 2.

  • Page 18: Features

    FEATURES SPECIFICATIONS • Responds to a fire in the presence of modulated OPERATING VOLTAGE— blackbody radiation (i.e. heaters, ovens, turbines) 24 Vdc nominal (18 Vdc minimum, 30 Vdc maximum). without false alarm. Maximum ripple is 2 volts peak-to-peak. • High speed capability. POWER CONSUMPTION—...
  • Page 19 ENCLOSURE MATERIAL— 100% REPRESENTS THE MAXIMUM DETECTION DISTANCE FOR A GIVEN FIRE. THE SENSITIVITY INCREASES AS THE ANGLE OF Copper-free aluminum (painted) or 316 stainless steel. INCIDENCE DECREASES. VIEWING ANGLE VIBRATION— 0° 15° 15° Conformance per FM 3260: 2000, MIL-STD 810C (Curve AW). 30°...
  • Page 20 CERTIFICATION— ® APPROVED For complete IECEx certification details, refer to Appendix D. For complete FM certification details, refer to Appendix A. For complete CSA certification details, refer to Appendix B. Performance per EN54-10, Certificate of Approval G-203083. EC-Certificate of Conformity ®...

  • Page 21: Replacement Parts

    REPLACEMENT PARTS ORDERING INFORMATION The detector is not designed to be repaired in the field. When ordering, please specify: If a problem should develop, refer to the Troubleshooting X2200 UV Flame Detector section. If it is determined that the problem is caused by Refer to the X2200 Model Matrix for details.
  • Page 22 X2200 MODEL MATRIX MODEL DESCRIPTION UV Flame Detector X2200 X2200M UV Flame Detector with Molybdenum Tube TYPE MATERIAL Aluminum Stainless Steel (316) TYPE THREAD TYPE 4 PORT, METRIC M25 4 PORT, 3/4" NPT TYPE OUTPUTS Relay Relay and 4-20 mA Eagle Quantum Premier (EQP) Relay and Pulse Addressable Module Only (Third Party Type)

  • Page 23: Performance Report

    APPENDIX A FM Approval and Performance Report THE FOLLOWING ITEMS, FUNCTIONS AND OPTIONS DESCRIBE THE FM APPROVAL: • Explosion-proof for Class I, Div. 1, Groups B, C and D (T5) Hazardous (Classified) Locations per FM 3615. • Dust-ignition proof for Class II/III, Div. 1, Groups E, F and G (T5) Hazardous (Classified) Locations per FM 3615. •...
  • Page 24 FM Approval and Performance Report – Continued RESPONSE CHARACTERISTICS IN THE PRESENCE OF FALSE ALARM SOURCES Very High Sensitivity (Standard Mode) Typical Distance Distance False Alarm Source Fire Source Response Time feet (m) feet (m) (seconds)* Sunlight, direct, modulated, reflected —...
  • Page 25 FM Approval and Performance Report – Continued FIELD OF VIEW Very High Sensitivity Typical Typical Distance Horizontal Vertical Fuel Size Response Time Response Mode feet (m) (degrees) (degrees) (seconds)* (seconds)* 42.5 n-Heptane 1 x 1 foot Low Arc (13) –45 –30 32 inch Methane...
  • Page 26 FM Approval and Performance Report – Continued MODEL X2200M The X2200M uses a sensor that has a broader spectrum than the standard sensor. It is designed to detect fires with unusual chemistry such as black powder. Consult factory for usage recommendations. X2200M RESPONSE CHARACTERISTICS High Sensitivity Distance...
  • Page 27 FM Approval and Performance Report – Continued X2200M FIELD OF VIEW High Sensitivity (Standard Mode) Typical Typical Distance Horizontal Vertical Fuel Size Response Time Response feet (m) (degrees) (degrees) (seconds) (seconds) Black Powder 40 grams (1.5) –45 –30 95-8549...

  • Page 28: Appendix B - Csa Approval

    APPENDIX B CSA Approval PRODUCTS CLASS 4818 04 - SIGNAL APPLIANCES - Systems - For Hazardous Locations Class I, Division 1, Groups B, C, and D (T5); Class II, Division 1, Groups E, F, and G (T5); Class I, Division 2, Groups A, B, C, and D (T3); Class II, Division 2, Groups F and G (T3); Class III;...

  • Page 29: Appendix C - Atex / Ce Approval

    APPENDIX C ATEX / CE Approval EC-TYPE EXAMINATION CERTIFICATE DEMKO 02 ATEX 132195X Increased Safety Model Flameproof Model II 2 G II 2 G 0539 0539 ® ® APPROVED APPROVED Ex d e IIC T5–T6 Gb Ex d IIC T5–T6 Gb T6 (T amb –50°C to +60°C) T6 (T amb –55°C to +60°C) T5 (T amb –50°C to +75°C)

  • Page 30: Appendix D - Iecex Approval

    APPENDIX D IECEx Approval IECEx CERTIFICATE OF CONFORMITY DEMKO IECEx ULD 06.0018X Ex d e IIC T5-T6 Gb Ex d IIC T4-T6 Gb T6 (T amb =–50°C to +60°C) T6 (T amb =–55°C to +60°C) T5 (T amb =–50°C to +75°C) T5 (T amb =–55°C to +75°C) IP66.

  • Page 31: Appendix E - Vds Approval

    APPENDIX E VdS Schadenverhütung GmbH Approval Performance per EN54-10, Certificate of Approval G-203083. EC-Certificate of Conformity 08 0786 – CPD – 20777 EN54-10 Flame detectors - Point detectors. SUBJECT MATTER OF THE APPROVAL UV Flame Detector Type X2200 for use in Automatic Fire Detection and Fire Alarm Systems. BASIS OF APPROVAL DIN EN 54, Part 10 (05/02) - Flame Detectors.
  • Page 32 95-8549 Detector Electronics Corporation 6901 West 110th Street Minneapolis, MN 55438 USA T: 952.941.5665 or 800.765.3473 F: 952.829.8750 W: http://www.det-tronics.com X3301 Multispectrum PointWatch Eclipse ® FlexVu ® Universal Display Eagle Quantum Premier ® E: det-tronics@det-tronics.com IR Flame Detector IR Combustible Gas Detector w/ GT3000 Toxic Gas Detector Safety System Det-Tronics, the DET-TRONICS logo, Protect•IR, and Automatic Optical Integrity (o i ) are registered trademarks or trademarks of Detector Electronics...
