REMOTE CONTROL
Remote control (CI-V) information
D Command formats
• GPS/D-PRS data (Continued)
Weather
Command: 20 03 0103, 0203
1 ~ 9
10
0 3 X X ∙∙∙∙∙∙ X X X X X X
Data number
17 ~ 22
X X X X X X
∙∙∙∙∙∙
36 ~ 38
33 34 35
X X X X X X X X
∙∙∙∙∙∙
42
43 44 45
X X X X X X X X X X
1 ~ 9: Call sign/SSID
(9 ASCII characters (A ~ Z, 0 ~ 9, /, -, space))
10, 11: Symbol (2 ASCII characters (00h ~ EFh))
12 ~ 16: Latitude (dd°mm�mmm format)
17 ~ 22: Longitude (ddd°mm�mmm format)
23 ~ 29: Date (UTC: yyyymmddHHMMSS)
( y: Year, m: Month, d: Day,
H: Hour, M: Minute, S: Second)
30, 31: Wind direction (1 degree steps)
32, 33: Wind speed (0�1 m/s steps)
34, 35: Gust speed (0�1 m/s steps)
36 ~ 37: Temperature (0�1°C steps)
Temperature (0= + degree, 1= – degree)
38:
39, 40: Rainfall (0�1 mm steps)
41, 42: Rainfall (24 hours) (0�1 mm steps)
43, 44: Rainfall (Midnight) (0�1 mm steps)
45, 46: Humidity (1% steps)
47 ~ 49: Barometric pressure (0�1 hPa steps)
L The item, that is not contained the received data, is filled
with "FF�"
L FF: No signal has been received since the power was
turned ON�

• GPS/D-PRS message

Command: 20 0401, 0402
1 ~ 9 10 ~ 52
• • • • • • X X
X X X X X X
(Variable length)
1 ~ 9: Call sign/SSID
(9 ASCII characters (A ~ Z, 0 ~ 9, /, -, space))
10 ~ 52: Message
(Up to 43 ASCII characters (00h ~ EFh))
L FF: No signal has been received since the power was
turned ON�
12 ~ 16
11
X X ∙∙∙∙∙∙ X X
23 ~ 29
30 31 32
X X X X X X X X
∙∙∙∙∙∙
40 41
39
X X X X X X X X
47 ~ 49
46
X X X X
∙∙∙∙∙∙

• RIT frequency settings

Command: 21 00
X X X

• DV TX data

Command: 22 00
X X
∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙
(Variable length)
1 ~ 30: TX data (Up to 30 Byte)
L"FA" to "FF" are entered after converted to "FF 0A"
to "FF 0F" automatically� Up to 60 Byte data can be
entered in this case�

• DV RX data (transceive)

Command: 22 0101
1 ~ 30: RX data (Up to 30 Byte)
L"FA" to "FF" are entered after converted to "FF 0A"
to "FF 0F" automatically� Up to 60 Byte data can be
entered in this case�

• MY position data

Command: 23 00
~
1 5
X X ∙∙∙∙∙∙∙ X X X X
16 17
X X X X X X
1 ~ 5: Latitude (dd°mm�mmm format)
6 ~ 11: Longitude (ddd°mm�mmm format)
12 ~ 15: Altitude (0�1 meter steps)
16, 17: Course (1 degree steps)
18 ~ 20: Speed (0�1 km/h steps)
21 ~ 27: Date (UTC: yyyymmddHHMMSS)
( y: Year, m: Month, d: Day,
H: Hour, M: Minute, S: Second)
25
X X X
00: + (plus)
01: – (minus)
1 ~ 30
X X
~ ~
6 11 12 15
∙∙∙∙∙∙∙ X X X X ∙∙∙∙∙∙∙ X X
~ ~
18 20 21 27
X X X X X X
∙∙∙∙∙∙∙ ∙∙∙∙∙∙∙
