Icom IC-705 Reference Manual page 14

REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
1A* 05 GPS > GPS TX Mode > D-PRS > TX Format > Item
0322 See p� 18�
0323 00/01
0324 See pp� 18
and 21�
0325 See p� 18�
0326 See p� 21�
0327 00 ~ 02
0328 000 ~ 360
0329 0000 ~ 1850
0330 00 ~ 09
0331 00 ~ 09
0332 00 ~ 09
0333 00 ~ 08
0334 00 ~ 42
GPS > GPS TX Mode > D-PRS > TX Format > Weather
0335 See pp� 18
and 21�
0336 00 ~ 42
0337 See p� 18�
0338 00 ~ 02
GPS > GPS TX Mode > NMEA
0339* 6 00/01
0340* 6 00/01
0341* 6 00/01
Description
Send/read the Item Name setting
(Up to 9 characters)
Send/read the Data Type setting
(00=Live Item, 01=Killed Item)
Send/read the Symbol setting
(2 characters)
Send/read the Comment setting
(Up to 43 characters)
Send/read the Position setting
Send/read the Data Extension setting
( 00=OFF, 01=Course/Speed,
02=Power/Height/Gain/Directivity)
Send/read the Course setting
(000 ~ 360=0º ~ 360º)
Send/read the Speed setting
( 0000=0km/h ~ 1850=1850km/h)
Send/read the Power setting
( 00=0W, 01=1W, 02=4W, 03=9W,
04=16W, 05=25W, 06=36W,
07=49W, 08=64W, 09=81W)
Send/read the Height setting
( 00=3m, 01=6m, 02=12m, 03=24m,
04=49m, 05=98m, 06=195m,
07=390m, 08=780m, 09=1561m)
Send/read the Gain setting
(00=0dB ~ 09=9dB)
Send/read the Directivity setting
( 00=Omni, 01=45ºNE, 02=90ºE,
03=135ºSE, 04=180ºS, 05=225ºSW,
06=270ºW, 07=315ºNW, 08=360ºN)
Send/read the SSID setting
( 00= - - -, 01=(- 0),
02= -1 ~ 16= -15,
17= -A ~ 42= -Z)
Send/read the Symbol setting
(2 characters)
Send/read the SSID setting
( 00= - - -, 01=(- 0),
02= -1 ~ 16= -15,
17= -A ~ 42= -Z)
Send/read the Comment setting
(Up to 43 characters)
Send/read the Time Stamp setting
(00=OFF, 01=DHM, 02=HMS)
GPS Sentence >
Send/read the RMC setting
(00=OFF, 01=ON)
GPS Sentence >
Send/read the GGA setting
(00=OFF, 01=ON)
GPS Sentence >
Send/read the GLL setting
(00=OFF, 01=ON)
Cmd� Sub cmd� Data
1A* 05 GPS > GPS TX Mode > NMEA
0342* 6 00/01
0343* 6 00/01
0344* 6 00/01
0345 See p� 18�
GPS > GPS Alarm
0346 See p� 21�
0347 00 ~ 02
GPS > GPS Logger
0348 00/01
0349 00 ~ 06
0350 00/01
0351 00/01
0352 00/01
0353 00/01
GPS
0354 00 ~ 06
DTMF > DTMF SET
0355 00 ~ 03
NB
0356 0000 ~ 0255
0357 00 ~ 09
0358 0000 ~ 0255
13
Description
GPS Sentence >
Send/read the GSA setting
(00=OFF, 01=ON)
GPS Sentence >
Send/read the VTG setting
(00=OFF, 01=ON)
GPS Sentence >
Send/read the GSV setting
(00=OFF, 01=ON)
Send/read the GPS Message setting
(Up to 20 characters)
Send/read the Alarm Area (Group)
setting
Send/read the Alarm Area (RX/
Memory) setting
( 00=Limited, 01=Extended,
02=Both)
Send/read the GPS Logger setting
(00=OFF, 01=ON)
Send/read the Record Interval setting
( 00=1sec, 01=5sec, 02=10sec,
03=30sec, 04=1min, 05=5min,
06=10min)
Record Sentence >
Send/read the RMC setting
(00=OFF, 01=ON)
Record Sentence >
Send/read the GGA setting
(00=OFF, 01=ON)
Record Sentence >
Send/read the VTG setting
(00=OFF, 01=ON)
Record Sentence >
Send/read the GSA setting
(00=OFF, 01=ON)
Send/read the GPS Auto TX setting
( 00=OFF, 01=30sec, 02=1min,
03=3min, 04=5min, 05=10min,
06=30min)
Send/read the DTMF Speed setting
( 00=100ms, 01=200ms,
02=300ms, 03=500ms)
Send/read the NB LEVEL setting
(0000=0% ~ 0255=100%)
Send/read the NB DEPTH setting
(00=1 ~ 09=10)
Send/read the NB WIDTH setting
(0000=1 ~ 0255=100)
