Icom IC-705 Reference Manual page 5

REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
14* 09 0000 ~ 0255
0A 0000 ~ 0255
0B 0000 ~ 0255
0C 0000 ~ 0255
0D 0000 ~ 0255
0E 0000 ~ 0255
0F 0000 ~ 0255
12 0000 ~ 0255
15 0000 ~ 0255
16 0000 ~ 0255
17 0000 ~ 0255
19 0000 ~ 0255
15* 1 01 00/01
02 0000 ~ 0255
05 00/01
07 00/01
11 0000 ~ 0255
12 0000 ~ 0255
13 0000 ~ 0255
14 0000 ~ 0255
15 0000 ~ 0255
16 0000 ~ 0255
16* 02 00 ~ 02
12 01 ~ 03
Description
Send/read CW pitch (5 Hz steps)
( 0000=300 Hz ~ 0128=600 Hz ~
0255=900 Hz)
Send/read the selected band's RF
power
(0000=Minimum ~ 0255=Maximum)
Send/read MIC gain
(0000=Minimum ~ 0255=Maximum)
Send/read keying speed
(0000=6 WPM ~ 0255=48 WPM)
Send/read Notch filter setting
( 0000=max� Counter Clockwise ~
0128=center ~ 0255=max� Clockwise)
Send/read the COMP level
(0000=0 ~ 0255=10)
Send/read the Break-IN Delay setting
(0000=2�0d ~ 0255=13�0d)
Send/read NB level
(0000=0% ~ 0255=100%)
Send/read Monitor audio [MONI]
level
(0000=0% ~ 0255=100%)
Send/read the VOX gain
(0000=0% ~ 0255=100%)
Send/read the Anti VOX gain
(0000=0% ~ 0255=100%)
Send/read LCD backlight brightness
(0000=0% ~ 0255=100%)
Read noise or S-meter squelch status
(00=Close, 01=Open)
Read S-meter level
( 0000=S0, 0120=S9,
0241=S9+60 dB)
Read various squelch (tone squelch,
and so on) status
(00=Close, 01=Open)
Read the OVF status
( 00=OVF indicator is OFF,
01=OVF indicator is ON)
Read the Po meter level
(0000=0% ~ 0143=50% ~ 0213=100%)
Read SWR meter level
( 0000=SWR1�0, 0048=SWR1�5,
0080=SWR2�0, 0120=SWR3�0)
Read ALC meter level
(0000=Minimum ~ 0120=Maximum)
Read COMP meter level
( 0000=0 dB ~ 0130=15 dB ~
0210=25�5 dB)
Read Vd meter level
(0000=0 V ~ 0075=5 V ~ 0241=16 V)
Read Id meter level
(0000=0 A ~ 0121=2 A ~ 0241=4 A)
Send/read the Preamp
( 00=OFF, 01=P�AMP1, 02=P�AMP2)
( In the 144 or 430 MHz bands,
00=OFF, 01=ON)
Send/read the AGC time constant
(01=FAST, 02=MID, 03=SLOW)
Cmd� Sub cmd� Data
16* 22 00/01
40 00/01
41 00/01
42 00/01
43 00/01
44 00/01
45 00/01
46 00/01
47 00 ~ 02
48 00/01
4B 00/01
4F 00/01
50 00/01
56 00/01
57 00 ~ 02
58 00 ~ 02
5B 00 ~ 02
5C 00 ~ 02
5D 00 ~ 03,
06 ~ 09
17* 3 See p� 16�
18 00
01* 4
4
Description
Send/read the Noise blanker
(00=OFF, 01=ON)
Send/read the Noise reduction
(00=OFF, 01=ON)
Send/read the Auto Notch function
(00=OFF, 01=ON)
Send/read the Repeater tone
(00=OFF, 01=ON)
Send/read the Tone squelch
(00=OFF, 01=ON)
Send/read the Speech compressor
(00=OFF, 01=ON)
Send/read the Monitor [MONI]
function
(00=OFF, 01=ON)
Send/read the VOX function
(00=OFF, 01=ON)
Send/read the BK-IN function
( 00=BK-IN OFF, 01=Semi BK-IN ON,
02=Full BK-IN ON)
Send/read the Manual Notch function
(00=OFF, 01=ON)
Send/read the DTCS function
(00=OFF, 01=ON)
Send/read the Twin peak filter
(00=OFF, 01=ON)
( Can be turned ON only when Mark
and Shift are set to 2125 Hz and
170 Hz, respectively)
Send/read the Dial lock function
(00=OFF, 01=ON)
Send/read DSP IF filter type in the
operating band
(00=SHARP, 01=SOFT)
Send/read the Manual Notch width
(00=WIDE, 01=MID, 02=NAR)
Send/read SSB transmit bandwidth
(00=WIDE, 01=MID, 02=NAR)
( One of following values is applied,
depending on the "COMP" status
(ON or OFF):
WIDE (Command: 1A 05 0017),
MID (Command: 1A 05 0018), or
NAR (Command: 1A 05 0019))
Send/read the DSQL (Digital Call
Sign squelch)/CSQL (Digital Code
squelch) setting
(DV mode only)
(00=OFF, 01=DSQL, 02=CSQL)
Send/read the GPS TX mode
(00=OFF, 01=D-PRS, 02=NMEA)
Send/read the Tone squelch function
( 00=OFF, 01=TONE, 02=TSQL,
03=DTCS, 06=DTCS (T),
07=TONE (T)/DTCS (R),
08=DTCS (T)/TSQL (R),
09=TONE (T)/TSQL (R))
Send CW messages
Turn OFF the transceiver
Turn ON the transceiver
