Icom IC-705 Reference Manual page 25

REMOTE CONTROL
Remote control (CI-V) information
D Command formats
• GPS/D-PRS data (Continued)
Object
Command: 20 03 0101, 0201
1 ~ 9
10
0 1 X X ∙∙∙∙∙∙ X X X X X X X X
Data number
17 ~ 22
X X X X X X
∙∙∙∙∙∙
29 ~ 31 32 ~ 38
X X X X X X
∙∙∙∙∙∙
43 ~ 51
42
X X X X X X
∙∙∙∙∙∙
1 ~ 9: Call sign/SSID
(9 ASCII characters (A ~ Z, 0 ~ 9, /, -, space))
10, 11: Symbol (2 ASCII characters (00h ~ EFh))
12 ~ 16: Latitude (dd°mm�mmm format)
17 ~ 22: Longitude (ddd°mm�mmm format)
23 ~ 26: Altitude (0�1 meter steps)
27, 28: Course (1 degree steps)
29 ~ 31: Speed (0�1 km/h steps)
32 ~ 38: Date (UTC: yyyymmddHHMMSS)
( y: Year, m: Month, d: Day,
H: Hour, M: Minute, S: Second)
39 ~ 42: See the table below�
39 Power 40 Height
Data (W) (m/ft)
0 0 3/10
1 1 6/20
2 4 12/40
3 9 24/80
4 16 49/160
5 25 98/320
6 36 195/640
7 49 390/1280
8 64 780/2560
9 81 1561/5120
43 ~ 51: Name
(9 ASCII characters (00h ~ EFh))
Type (1= Live, 0= Killed)
52:
L The item, that is not contained the received data, is filled
with "FF�"
L FF: No signal has been received since the power was
turned ON�
12 ~ 16
11
∙∙∙∙∙∙ X X
23 ~ 26
27 28
X X X X X X
∙∙∙∙∙∙
39 40 41
X X X X X X X X
∙∙∙∙∙∙
52
X X
41 Gain 42 Directivity
(dB) (deg)
0 Omni-direction
1 45° NE
2 90° E
3 135° SE
4 180° S
5 225° SW
6 270° W
7 315° NW
8 360° N
9 —
Item
Command: 20 03 0102, 0202
1 ~ 9
0 2 X X ∙∙∙∙∙∙ X X
Data number
17 ~ 22
X X X X
∙∙∙∙∙∙
29 ~ 31
X X X X X X
∙∙∙∙∙∙
36 ~ 44
X X X X
∙∙∙∙∙∙
1 ~ 9: Call sign/SSID
(9 ASCII characters (A ~ Z, 0 ~ 9, /, -, space))
10, 11: Symbol (2 ASCII characters (00h ~ EFh))
12 ~ 16: Latitude (dd°mm�mmm format)
17 ~ 22: Longitude (ddd°mm�mmm format)
23 ~ 26: Altitude (0�1 meter steps)
27, 28: Course (1 degree steps)
29 ~ 31: Speed (0�1 km/h steps)
32 ~ 35: See the table below�
32 Power
Data
(W)
0 0
1 1
2 4
3 9
4 16
5 25
6 36
7 49
8 64
9 81
36 ~ 44: Name
(9 ASCII characters (00h ~ EFh))
Type (1= Live, 0= Killed)
45:
L The item, that is not contained the received data, is filled
with "FF�"
L FF: No signal has been received since the power was
turned ON�
24
12 ~ 16
10 11
X X X X X X ∙∙∙∙∙∙ X X
23 ~ 26
27 28
X X X X X X X X
∙∙∙∙∙∙
32 33 34 35
X X X X X X
45
X X
33 Height 34 Gain 35 Directivity
(m/ft) (dB)
3/10 0 Omni-direction
6/20 1
12/40 2
24/80 3 135° SE
49/160 4
98/320 5 225° SW
195/640 6
390/1280 7 315° NW
780/2560 8
1561/5120 9
(deg)
45° NE
90° E
180° S
270° W
360° N
—
