Icom IC-705 Reference Manual page 10

REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
1A* 05 SET > Display
0145 00 ~ 03
0146 00/01
0147 00/01
0148 00 ~ 04
0149 00/01
0150 00/01
0151 00/01
0152 00 ~ 02
0153 00/01
0154 00/01
0155 00/01
0156 00/01
0157 00/01
0158 00 ~ 02
0159 00/01
0160 00 ~ 03
0161 00/01
0162 00 ~ 03
0163 00/01
0164 00/01
Description
Send/read the RX Call Sign Display
setting
( 00=OFF, 01=Normal,
02=RX Hold, 03=Hold)
Send/read the RX Position Indicator
setting
(00=OFF, 01=ON)
Send/read the RX Position Display
setting
(00=OFF, 01=ON)
Send/read the RX Position Display
Timer setting
( 00=5sec, 01=10sec, 02=15sec,
03=30sec, 04=Hold)
Send/read the Reply Position
Display setting
(00=OFF, 01=ON)
Send/read the RX Picture Indicator
setting
(00=OFF, 01=ON)
Send/read the DV RX Backlight setting
(00=OFF, 01=ON)
Send/read the TX Call Sign Display
setting
( 00=OFF, 01=Your Call Sign,
02=My Call Sign)
Send/read the Scroll Speed setting
(00=Slow, 01=Fast)
Send/read the Opening Message setting
(00=OFF, 01=ON)
Send/read the Power ON Check setting
(00=OFF, 01=ON)
Display Unit >
Send/read the Latitude/Longitude
setting
( 0 0=ddd°mm.mm',
01=ddd°mm'ss")
Display Unit >
Send/read the Altitude/Distance setting
(00=m, 01=ft/mi)
Display Unit >
Send/read the Speed setting
(00=km/h, 01=mph, 02=knots)
Display Unit >
Send/read the Temperature setting
(00=°C, 01=°F)
Display Unit >
Send/read the Barometric setting
(00=hPa, 01=mb, 02=mmHg, 03=inHg)
Display Unit >
Send/read the Rainfall setting
(00=mm, 01=inch)
Display Unit >
Send/read the Wind Speed setting
(00=m/s, 01=km/h, 02=mph, 03=knots)
Send/read the Display Language setting
(00=English, 01=Japanese)
Send/read the System Language setting
(00=English, 01=Japanese)
Cmd� Sub cmd� Data
1A* 05 SET > Time Set
0165 20000101 ~
20991231
0166 0000 ~ 2359
0167 00/01
0168 See p� 18�
0169 00/01
0170 See p� 20�
SET > SD Card
0171 00 ~ 02
0172 00 ~ 02
SCOPE > SCOPE SET
0173 00/01
0174 00 ~ 02
0175 00 ~ 02
0176 00/01
0177 00/01
0178 00 ~ 03
0179 00/01
0180 See p� 20�
0181 See p� 20�
0182 See p� 20�
0183 00/01
9
Description
Date/Time >
Send/read the Date setting
( 20000101=2000/1/1 ~
20991231=2099/12/31)
Date/Time >
Send/read the Time setting
(0000=00:00 ~ 2359=23:59)
Date/Time >
Send/read the NTP Function setting
(00=OFF, 01=ON)
Date/Time >
Send/read the NTP Server Address
setting
(Up to 64 characters)
Date/Time >
Send/read the GPS Time Correct
setting
(00=OFF, 01=Auto)
Send/read the UTC Offset setting
Import/Export > CSV Format >
Send/read the Separator/Decimal
setting
( 00=Separator is " , " and Decimal is " � ,"
01=Separator is " ; " and Decimal is " � ,"
02=Separator is " ; " and Decimal is " , ")
Import/Export > CSV Format >
Send/read the Date setting
( 00="yyyy/mm/dd," 01="mm/dd/yyyy,"
02="dd/mm/yyyy")
Send/read the Scope during Tx
(CENTER Type) setting
(00=OFF, 01=ON)
Send/read the Max Hold setting
( 00=OFF, 01=10s Hold, 02=ON)
Send/read the CENTER Type
Display setting
( 00=Filter Center,
01=Carrier Point Center,
02=Carrier Point Center (Abs� Freq�))
Send/read the Marker Position (FIX
Type) setting
(00=Filter Center, 01=Carrier Point)
Send/read the VBW setting
(00=Narrow, 01=Wide)
Send/read the Averaging setting
(00=OFF, 01=2, 02=3, 03=4)
Send/read the Waveform Type setting
(00=Fill, 01=Fill+Line)
Send/read the Waveform Color
(Current) setting
Send/read the Waveform Color
(Line) setting
Send/read the Waveform Color
(Max Hold) setting
Send/read the Waterfall Display setting
(00=OFF, 01=ON)
