Icom IC-705 Reference Manual page 13

REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
1A* 05 SCAN > SCAN SET
0280 00/01
GPS
0281 00 ~ 02
0282 00/01
0283 00/01
0284 00 ~ 05
0285 00/01
0286 See p� 21�
0287 00 ~ 02
GPS > GPS TX Mode > D-PRS
0288 See p� 18�
0289 00 ~ 03
GPS > GPS TX Mode > D-PRS > TX Format > Position
0290 00 ~ 03
0291 See pp� 18
and 21�
0292 See pp� 18
and 21�
0293 See pp� 18
and 21�
0294 See pp� 18
and 21�
0295 00 ~ 42
0296 00 ~ 03
0297 See p� 18�
0298 See p� 18�
0299 See p� 18�
0300 See p� 18�
Description
Send/read the MAIN DIAL Operation
(SCAN) setting
(00=OFF, 01=Up/Down)
GPS Set >
Send/read the GPS Select setting
(00=OFF, 01=ON, 02=Manual)
GPS Set > GPS Option >
Send/read the SBAS setting
(00=OFF, 01=ON)
GPS Set > GPS Option >
Send/read the GLONASS setting
(00=OFF, 01=ON)
GPS Set > GPS Option >
Send/read the Power Save setting
( 00=OFF, 01=1min, 02=2min,
03=4min, 04=8min, 05=Auto)
GPS Set > GPS Option >
Send/read the Satellite Information
Out setting
( 00=GPS/QZSS/GLONASS,
01=GPS Only)
GPS Set >
Send/read the Manual Position setting
Send/read the GPS TX Mode setting
(00=OFF, 01=D-PRS, 02=NMEA)
Send/read the Unproto Address setting
(Up to 56 characters)
Send/read the TX Format setting
( 00=Position, 01=Object,
02=Item, 03=Weather)
Send/read the Symbol setting
( 00=No�1, 01=No�2,
02=No�3, 03=No�4)
Send/read the Symbol No�1 setting
(2 characters)
Send/read the Symbol No�2 setting
(2 characters)
Send/read the Symbol No�3 setting
(2 characters)
Send/read the Symbol No�4 setting
(2 characters)
Send/read the SSID setting
( 00= - - -, 01=(- 0),
02= -1 ~ 16= -15,
17= -A ~ 42=-Z)
Send/read the Comment setting
(00=No�1, 01=No�2, 02=No�3, 03=No�4)
Send/read the Comment No�1 setting
(Up to 43 characters)
Send/read the Comment No�2 setting
(Up to 43 characters)
Send/read the Comment No�3 setting
(Up to 43 characters)
Send/read the Comment No�4 setting
(Up to 43 characters)
Cmd� Sub cmd� Data
1A* 05 GPS > GPS TX Mode > D-PRS > TX Format > Position
0301 00 ~ 02
0302 00/01
0303 00 ~ 02
0304 00 ~ 09
0305 00 ~ 09
0306 00 ~ 09
0307 00 ~ 08
GPS > GPS TX Mode > D-PRS > TX Format > Object
0308 See p� 18�
0309 00/01
0310 See pp� 18
and 21�
0311 See p� 18�
0312 See p� 21�
0313 00 ~ 02
0314 000 ~ 360
0315 0000 ~ 1850
0316 00 ~ 09
0317 00 ~ 09
0318 00 ~ 09
0319 00 ~ 08
0320 00 ~ 42
0321 00/01
12
Description
Send/read the Time Stamp setting
(00=OFF, 01=DHM, 02=HMS)
Send/read the Altitude setting
(00=OFF, 01=ON)
Send/read the Data Extension setting
( 00=OFF, 01=Course/Speed,
02=Power/Height/Gain/Directivity)
Send/read the Power setting
( 00=0W, 01=1W, 02=4W, 03=9W,
04=16W, 05=25W, 06=36W,
07=49W, 08=64W, 09=81W)
Send/read the Height setting
( 00=3m, 01=6m, 02=12m, 03=24m,
04=49m, 05=98m, 06=195m,
07=390m, 08=780m, 09=1561m)
Send/read the Gain setting
(00=0dB ~ 09=9dB)
Send/read the Directivity setting
( 00=Omni, 01=45ºNE, 02=90ºE,
03=135ºSE, 04=180ºS, 05=225ºSW,
06=270ºW, 07=315ºNW, 08=360ºN)
Send/read the Object Name setting
(Up to 9 characters)
Send/read the Data Type setting
(00=Live Object, 01=Kill Object)
Send/read the Symbol setting
(2 characters)
Send/read the Comment setting
(Up to 43 characters)
Send/read the Position setting
Send/read the Data Extension setting
( 00=OFF, 01=Course/Speed,
02=Power/Height/Gain/Directivity)
Send/read the Course setting
(000=0º ~ 360=360º)
Send/read the Speed setting
(0000=0km/h ~ 1850=1850km/h)
Send/read the Power setting
( 00=0W, 01=1W, 02=4W, 03=9W,
04=16W, 05=25W, 06=36W,
07=49W, 08=64W, 09=81W)
Send/read the Height setting
( 00=3m, 01=6m, 02=12m, 03=24m,
04=49m, 05=98m, 06=195m,
07=390m, 08=780m, 09=1561m)
Send/read the Gain setting
(00=0dB ~ 09=9dB)
Send/read the Directivity setting
( 00=Omni, 01=45ºNE, 02=90ºE,
03=135ºSE, 04=180ºS, 05=225ºSW,
06=270ºW, 07=315ºNW, 08=360ºN)
Send/read the SSID setting
( 00= - - -, 01=(- 0),
02= -1 ~ 16= -15,
17= -A ~ 42= -Z)
Send/read the Time Stamp setting
(00=DHM, 01=HMS)
