REMOTE CONTROL
Remote control (CI-V) information
D Command table
Cmd� Sub cmd� Data
22 00 See p� 25�
01 00* 00/01
01 See p� 25�
02* 00/01
03* 00/01
04* 00/01
05* 00 ~ 10
23 00* 1 See p� 25�
01* 00/01/03
02* See p� 21�
24 00 00* 00/01
01 00/01
25* See p� 26�
26* See p� 26�
27* 00 See p� 26�
10 00/01
11 00/01
12 00
13 00
14 0000/
0001
15 See p� 27�
16 0001 ~ 0003
17 0000/
0001
19 See p� 27�
Description
Set the DV TX data (Up to 30 byte)
Set the Auto DV RX data output
(00=OFF, 01=ON)
Set the DV RX data for transceive
SET > DV Set >
Send/read the DV Data TX setting
(00=PTT, 01=Auto)
SET > DV Set > DV Fast Data >
Send/read the Fast Data setting
(00=OFF, 01=ON)
SET > DV Set > DV Fast Data >
Send/read the GPS Data Speed setting
(00=Slow, 01=Fast)
SET > DV Set > DV Fast Data >
Send/read the TX Delay (PTT) setting
( 00=OFF, 01=1sec ~ 10=10sec)
Read the position status
GPS > GPS Set >
Send/read the GPS Select setting
(00=OFF, 01=ON, 03=Manual)
GPS > GPS Set >
Send/read the Manual Position setting
Send/read TX output power setting
(00=OFF, 01=ON)
Set the TX output power for transceive
(00=OFF, 01=ON)
Send/read the selected or
unselected VFO frequency
Send/read the selected or unselected
VFO's operating mode and filter
Read the Scope waveform data
( Only when "Scope ON/OFF status"
(Command: 27 10) and "Scope
data output" (Command: 27 11) are
set to "ON," outputs the waveform
data to the controller�)
Send/read the Scope ON/OFF status
(00=OFF, 01=ON)
Send/read the Scope wave data output
(00=OFF, 01=ON)
Send/read the Main or Sub scope
setting
(00=Main (fixed))
Send/read the Single/Dual scope setting
(00=Single (fixed))
Send/read the Scope Center mode
or Fixed mode setting
( 0000=CENTER mode,
0001=FIX mode)
Send/read the Span setting in the
Center mode Scope
Send/read the Edge number setting
in the Fixed mode Scope
Send/read the Scope hold function
ON/OFF status
(0000=OFF, 0001=ON)
Send/read the Scope Reference
level setting
Cmd� Sub cmd� Data
27* 1A 0000 ~ 0002
1B 00/01
1C 00 ~ 02
1D 0000/
0001
1E See p� 27�
28 00 00 ~ 08
*(Asterisk) Send/read data
* 1 Read only data
* 2 Send only data
* 3 In the CW mode, if the [PTT] or an external TX switch is ON, or the
Break-in function is ON, a message will be transmitted as CW code
when you send it from your PC�
* Sending the power ON command (18 01) turns ON the transceiver
4
when the transceiver is OFF (Standby/Shutdown)�
* To insert a counter, first clear the other channel's counter�
5
* 6 Set at least 1 GPS sentence to ON�
Up to 4 GPS sentences can be set to ON at the same time�
* 7 Output setting is automatically set to OFF after turning OFF the
transceiver�
15
Description
Send/read the Sweep speed setting
(0000=FAST, 0001=MID, 0002=SLOW)
SCOPE > SCOPE SET >
Send/read the Scope during Tx
(CENTER TYPE) setting
(00=OFF, 01=ON)
SCOPE > SCOPE SET >
Send/read the CENTER Type
Display setting
( 00=Filter Center,
01=Carrier Point Center,
02=Carrier Point Center (Abs� Freq�))
Send/read the Scope VBW setting
(0000=NAR, 0001=WIDE)
Send/read the Scope Fixed edge
frequencies
Transmit the Voice TX Memory
( 00=Stop, 01=T1 ~ 08=T8)
