A-2
Compact™ IO Isolated Thermocouple Module
Thermocouple Type
N (-200°C to 1300°C)
Thermocouple Type
N (-210°C to -200°C)
Thermocouple Type
T (-230°C to 400°C)
Thermocouple Type
T (-270°C to -230°C)
Thermocouple Type
K (-225°C to 1370°C)
Thermocouple Type
K (-270°C to -225°C)
Thermocouple Type
E (-210°C to 1000°C)
Thermocouple Type
E (-270°C to -210°C)
Thermocouple Types
S and R
Thermocouple Type C
Thermocouple Type B
Thermocouple Type L
CJC Sensor range
CJC Sensor accuracy
CJC Measurement accuracy
CJC Profile accuracy
CJC Total accuracy
(sum of above)
Millivolt Inputs
8
Repeatability (at 25°C)
Thermocouple Types
J, L and N
Thermocouple Types
N (-110°C to 1300°C)
Thermocouple Types
N (-210°C to -110°C)
Thermocouple Types
T (-170°C to 400°C)
Thermocouple Types
T (-270°C to -170°C)
Thermocouple Type
K (-170°C to 1370°C)
Thermocouple Type
K (-270°C to -170°C)
Thermocouple Type
E (-220°C to 1000°C)
Thermocouple Type
E (-270°C to -220°C)
Thermocouple Types
S and R
8
Repeatability for:
16.7 Hz filter is 2X the repeatability of the 4.17Hz filter
19.6 Hz filter is 2X the repeatability of the 4.17Hz filter
62 Hz filter is 4X the repeatability of the 4.17Hz filter
470 Hz filter is 10X the repeatability of the 4.17Hz filter
User's Manual Pub. 0300244-01 Rev. A
+/- 1 degrees C maximum @ 25 degrees C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 1.5 degrees C maximum @ 0 – 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 1.2 degrees C maximum @ 25°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 1.8 degrees C maximum @ 0 – 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 1 degrees C maximum @ 25°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 1.5 degrees C maximum @ 0 – 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 5.4 degrees C maximum @ 25°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 7.0 degrees C maximum @ 0 – 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 1 degrees C maximum @ 25°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 1.5 degrees C maximum @ 0 – 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 7.5 degrees C maximum @ 25°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 10 degrees C maximum @ 0 – 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 0.5 degrees C maximum @ 25°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 0.8 degrees C maximum @ 0 – 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 4.2 degrees C maximum @ 25°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 6.3 degrees C maximum @ 0 – 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 1.7 degrees C maximum @ 25°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 2.6 degrees C maximum @ 0 – 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 1.8 degrees C maximum @ 25°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 3.5 degrees C maximum @ 0 – 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 3.0 degrees C maximum @ 25°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 4.5 degrees C maximum @ 0 – 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 0.6 (TBD) degrees C maximum @ 25°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 0.9 (TBD) degrees C maximum @ 0 – 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
0 to 85 degrees C
+/- 0.2 degrees C maximum
+/- 0.1 degrees C maximum
+/- 0.7 degrees C maximum
+/- 1.0 degrees C maximum
+/- 15 uV maximum for +/- 50 mV inputs @ 25°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 25 uV maximum for +/- 50 mV inputs @ 0 - 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 20 uV maximum for +/- 100 mV inputs @ 25°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz filters.
+/- 30 uV maximum for +/- 100 mV inputs @ 0 - 60°C for 4.17 Hz, 10 Hz, 16.7 Hz, and 19.6 Hz
filters.
Note: Accuracy is dependent on the ADC filter selection, data format, and input noise.
4.17 Hz and 10Hz filter
+/- 0.1°C
+/- 0.1°C
+/- 0.25°C
+/- 0.1°C
+/- 1.5°C
+/- 0.1°C
+/- 2.0°C
+/- 0.1°C
+/- 1.0°C
+/- 0.4°C
