Section 5.7
Error Codes
Table 5-3 (Extended Error Codes)
Hex
Error Type
Equivalent
X000
No Error
General
X200
Common
X201
Hardware
Error
X300
X301
X30B
Hardware
X30C
Specific
X30D
Error
X30E
X30F
X310
X400
X401
X402
X403
X404
X405
X406
X407
X408
Module
X409
Specific
Configuration
X40A
Error
X40B
X40C
X40D
X40E
X40F
X410
X411
X412
X413
User's Manual Pub. 0300244-01 Rev. A
Chapter 5: Diagnostics and Troubleshooting
If you set the fields in the configuration file to invalid or unsupported values, the module
generates a critical error.
Table 5-3 Extended Error Codes on page 5-5 lists the possible module-specific
configuration error codes defined for the modules.
The table below explains the extended error code.
Extended Error
Module
Information Code
Error
Code
(Binary)
(Binary)
000
0 0000 0000
001
0 0000 0000
001
0 0000 0001
001
1 0000 0000
001
1 0000 0001
001
1 0000 1011
001
1 0000 1100
001
1 0000 1101
001
1 0000 1110
001
1 0000 1111
001
1 0001 0000
010
0 0000 0000
010
0 0000 0001
010
0 0000 0010
010
0 0000 0011
010
0 0000 0100
010
0 0000 0101
010
0 0000 0110
010
0 0000 0111
010
0 0000 1000
010
0 0000 1001
010
0 0000 1010
010
0 0000 1011
010
0 0000 1100
010
0 0000 1101
010
0 0000 1110
010
0 0000 1111
010
0 0001 0000
010
0 0001 0001
010
0 0001 0010
010
0 0001 0011
Error Description
No Errors
General Hardware error; no additional information
Power-up reset state
General Hardware Error (ASIC)
H/W ROM Error (Calibration Error)
Channel 0 ADC Error
Channel 1 ADC Error
Channel 2 ADC Error
Channel 3 ADC Error
Channel 4 ADC Error
Channel 5 ADC Error
General Config Error: no additional information
invalid input type selected ch0
invalid input type selected ch1
invalid input type selected ch2
invalid input type selected ch3
invalid input type selected ch4
invalid input type selected ch5
invalid input filter selected ch0
invalid input filter selected ch1
invalid input filter selected ch2
invalid input filter selected ch3
invalid input filter selected ch4
invalid input filter selected ch5
Invalid input format selected ch0
Invalid input format selected ch1
Invalid input format selected ch2
Invalid input format selected ch3
Invalid input format selected ch4
Invalid input format selected ch5
An unused bit has been set for ch0 (C:e.0)
5-5
