Compact™ IO Isolated Thermocouple Module
User's Manual Pub. 0300244-01 Rev. A
3) Put the controller in Run mode. During a normal start-up, the module status
LED turns on.
Note: If the module status LED does not turn on, cycle power. If the condition
persists, contact your local distributor or Spectrum Controls for assistance.
Step 6: Monitor the module status to
check if the module is operating
correctly
Module and channel configuration errors are reported to the controller. These errors are
typically reported in the controller's I/O status file.
Channel status data is also reported in the module's input data table, so these bits can be
used in your control program to flag a channel error.
Reference
Chapter 5(Diagnostics and
Troubleshooting)
