5-6
Compact™ IO Isolated Thermocouple Module
Hex
Error Type
Equivalent
X414
X415
X416
X417
X418
X419
Section 5.8
Module Inhibit
Function
User's Manual Pub. 0300244-01 Rev. A
Extended Error
Module
Information Code
Error
(Binary)
Code
(Binary)
010
0 0001 0100
010
0 0001 0101
010
0 0001 0110
010
0 0001 0111
010
0 0001 1000
010
0 0001 1001
Some controllers support the module inhibit function. See your controller manual for
details.
Whenever the 1769sc-IT6I module is inhibited, the module continues to provide
information about changes at its inputs to the 1769 CompactBus master (for example, a
CompactLogix controller).
Error Description
An unused bit has been set for ch1 (C:e.1)
An unused bit has been set for ch2 (C:e.2)
An unused bit has been set for ch3 (C:e.3)
An unused bit has been set for ch4 (C:e.4)
An unused bit has been set for ch5 (C:e.5)
An unused bit has been set for Module Configuration Register
(C:e.6)
