Analog Devices ADSP-CM403F EZ-KIT Lite Manual page 68

A
1
UART0RTS_EN
PB_04/PWM2_SYNC/UART0_RTS/SPT0_ATDV/SMC0_D12/CNT1_UD
UART0RX_EN
PC_01/UART0_RX/SMC0_A05/TM0_ACI5
2
UART0CTS_EN
PB_05/PWM2_TRIP0/UART0_CTS/TM0_TMR7/SMC0_D13/CNT1_DG
UART0CTS_RTS_LPBK
3
UART0CTS_RST_EN
CTS
4
A
B
3.3V
R54 R56 R55
10K 10K 10K
0402 0402 0402
DNP
U10
1
OE
2 4
A B
PI3A125
SC70_5
U11
1
OE
2 4
A B
PI3A125
SC70_5
R57 R58
10K 10K
0402 0402
3.3V
R59 R60 R61
10K 10K 10K
0402 0402 0402
U12
1
OE
2 4
A B
PI3A125
SC70_5
U13
1
OE
2 4
A B
PI3A125
SC70_5
U14
1
OE
2 4
A B
PI3A125
SC70_5
B
C
3.3V
3.3V
C61 C66 C55 U23
10UF 0.1UF 0.1UF
0805 0402 0402 A2
VCC0 VISO0
B1
VCC1 VISO1
B2
VCC2 VISO2
V+
C1+
C1-
C2+
C2-
D1
PC_02/UART0_TX/TRACE_D03/SPI0_RDY
TIN1 TOUT1
F1
TIN2 TOUT2
R63 33 H1
ROUT1 RIN1
0402 K1
ROUT2 RIN2
R62 33
0402
C1
GND0
C2
GND1 V-
D2
GND2
E1
GND3
E2
GND4
F2
GND5
G1
GND6 GND_ISO0
G2
GND7 GND_ISO1
H2
GND8 GND_ISO2
J1
GND9 GND_ISO3
J2
GND10 GND_ISO4
K2
GND11 GND_ISO5
L2
GND12 GND_ISO6
ADM3252E
BGA44C100P11X11_1200X1200X103
3.3V
Default
C63 C64 C65 C115 C114
0.1UF 0.1UF 0.1UF 0.1UF 0.1UF
0402 0402 0402 0402 0402
3.3V
SW1
C
2
1 3
0
7 5
6
SWT027
ROTARY
C
A10
B10
C10
C56 C62 C60
0.1UF 10UF 0.1UF
0402 0805 0402
C57
B11 0.10UF
0402
C11
C58
E11 0.10UF
0402
G11
G10 GND2
D11
F11
H11
K11
J11
D10
E10
F10
H10 C59
J10 0.10UF
K10 0402
L10
GND2 GND2
BOOT MODE SWITCH (SW1)
Bootmode (1:0)
00 No Boot
01 SPI Master Boot (internal SPI2)
10 SPI Slave Boot (SPI0)
11 UART Boot (UART0)
1
SYS_BMODE0
2
SYS_BMODE1
4
4
R64 R66 R65
10K 10K 10K
0402 0402 0402
ANALOG
DEVICES
Title ADSP-CM403F EZ-KIT
RS-232, BOOT CONN
Size Board No.
C
Date
08/27/2013
D
1
RS-232
J1
1
6
2
7
3
8
4
9
5
2
CON038
DB9
GND2
3
20 Cotton Road
Nashua, NH 03063
4
PH: 1-800-ANALOGD
Rev
A0342-2012
1.0
Sheet 6 of 10
