Industrial Electronic Devices

Each SNMP variable created will have its own OID and it will be created following this rule:

OID 1 (first row of "Set SNMP Access -> SNMP Read" table): .1.3.6.1.4.1.49314.1.1.1.4.9.1

OID 2 (second row of "Set SNMP Access -> SNMP Read" table): .1.3.6.1.4.1.49314.1.1.1.4.9.2

OID X (Xth row of "Set SNMP Access -> SNMP Read" table): .1.3.6.1.4.1.49314.1.1.1.4.9.X

The memory blocks are accessible with these OIDs:

Block1: .1.3.6.1.4.1.49314.1.1.1.4.1.0

Block2: .1.3.6.1.4.1.49314.1.1.1.4.2.0

Block3: .1.3.6.1.4.1.49314.1.1.1.4.3.0

Block4: .1.3.6.1.4.1.49314.1.1.1.4.4.0

Block5: .1.3.6.1.4.1.49314.1.1.1.4.5.0

Block6: .1.3.6.1.4.1.49314.1.1.1.4.6.0

Block7: .1.3.6.1.4.1.49314.1.1.1.4.7.0

Block8: .1.3.6.1.4.1.49314.1.1.1.4.8.0

ADFweb.com Srl – IT31010 – Mareno – Treviso

User Manual CAN / SNMP Agent

Document code: MN67155_ENG

INFO:

www.adfweb.com

Phone +39.0438.30.91.31

Revision 1.100

Pagina 27 di 37
