CHARACTERISTICS:
The HD67752-A1 is IEC 61850 Server / PROFINET Slave - Converter.
It allows for the following characteristics:
Isolation between Ethernet - Power Supply;
Two-directional information between IEC 61850 bus and PROFINET bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67752 software on your PC in order to perform the following:
Define the parameters of IEC 61850 line;
Define the parameters of PROFINET line;
Define IEC 61850 variables that contains the data to read from PROFINET side;
Define IEC 61850 variables that contains the data to write from PROFINET side;
Update the device.
ADFweb.com S.r.l.
User Manual IEC 61850 Server / PROFINET Slave
Document code: MN67752_ENG
Revision 1.000
Page 6 of 28
